TC Remanufacturing CT38 Automatic Transmission Torque Converter

Reliable Automatic Transmission Torque Converter for Hyundai and Kia

The TC Remanufacturing CT38 automatic transmission torque converter is designed as a standard replacement part for select Hyundai and Kia models. Engineered to meet OEM specifications, this torque converter supports smooth power transfer and efficient vehicle operation.

• Bolt Circle Diameter: 8.75 inches
• Converter Diameter: 10.1 inches
• Lock-Up Type: Yes, for improved fuel efficiency
• Hub Type: Slotted / stepped for secure fitment
• Mounting Thread Size: 10mm x 1.25
• Mounting Type: 4 pads oval
• Pilot Diameter: 1.06 inches with 0.48 inches pilot length
• Spline Count: 20
• Stall Speed: Low to medium
• Compatible with converter codes G4 and he

Technical Details and Compatibility

The CT38 torque converter is specifically designed for automatic transmissions in Hyundai Elantra, Kia Forte, Forte Koup, Soul, and Spectra models. Its 10.1-inch diameter and 8.75-inch bolt circle ensure precise alignment and fitment. The slotted and stepped hub type provides a secure connection to the transmission input shaft, while the 20-spline count matches factory specifications. The lock-up feature enhances fuel economy by reducing slippage during highway driving. This torque converter supports a low to medium stall speed, suitable for everyday driving conditions and maintaining smooth acceleration.

Common Applications and Problem Resolution

• Replacement for worn or damaged torque converters in Hyundai Elantra and Kia Forte transmissions
• Addresses issues with transmission slipping or shuddering
• Resolves poor fuel efficiency related to torque converter lock-up failure
• Corrects abnormal stall speeds affecting vehicle acceleration
• Improves overall transmission performance and drivability

Installation Notes and Tips

Ensure the torque converter is properly aligned with the transmission input shaft splines and pilot diameter during installation. Verify that the mounting threads and bolt circle match the vehicle’s transmission housing. It is recommended to inspect the transmission fluid and replace it if contaminated. Proper torque specifications should be followed for mounting bolts to avoid leaks or misalignment.

Quality Assurance and Warranty

TC Remanufacturing produces the CT38 torque converter to meet industry standards for durability and performance. This part undergoes rigorous testing to ensure compatibility and reliability in Hyundai and Kia automatic transmissions. Please refer to the manufacturer’s warranty documentation for specific coverage details.
