Timken 222535 Automatic Transmission Pinion Seal - Front, Rear or Rear Outer

Reliable Automatic Transmission Pinion Seal for Select Vehicles

The Timken 222535 automatic transmission pinion seal is engineered to provide a precise fit and durable sealing performance. Designed with S-nitrile material, this seal ensures resistance to heat and transmission fluids, making it suitable for various Audi, Chevrolet, Lexus, Suzuki, Toyota, and Volkswagen models.

• Constructed from durable S-nitrile material for enhanced fluid resistance
• Outside diameter measures 1.505 inches (38.23 mm) for accurate housing fit
• Shaft diameter of 0.984 inches (25.00 mm) ensures proper sealing around the pinion shaft
• Housing bore dimensions of 1.496 inches (38.00 mm) for secure installation
• Width of 0.276 inches (7.00 mm) provides reliable sealing depth
• Clockwise (CW) helix type design for optimal sealing performance

Detailed Description of Timken 222535 Pinion Seal

The Timken 222535 automatic transmission pinion seal is manufactured with precision to maintain the integrity of your vehicle's transmission system. Its S-nitrile composition offers excellent resistance to heat, oil, and wear, which is critical for maintaining a leak-free seal in demanding transmission environments. The seal's dimensions, including a 1.505-inch outside diameter and a 0.984-inch shaft diameter, are designed to match specific transmission housings and shafts, ensuring a tight fit and preventing fluid leaks. The clockwise helix type aids in directing fluid away from the seal lip, enhancing durability and performance.

Compatible Vehicles and Applications

This pinion seal is compatible with a range of vehicles, including Audi 80 and 90 models, Chevrolet Tracker and Sidekick, Lexus ES300h, RX450h, RX450hL, NX300h, and HS250h, Suzuki Sidekick and Tracker, Toyota Avalon, Camry, Corolla, Corona, Highlander, and Volkswagen Fox and Starlet. The Timken 222535 is designed to meet the specific transmission sealing requirements of these models, ensuring proper fit and function.

• Prevents transmission fluid leaks in automatic transmissions
• Maintains proper lubrication of transmission pinion shaft
• Reduces risk of transmission damage due to fluid loss
• Helps avoid costly repairs related to seal failure
• Ensures smooth operation of transmission components

Installation Notes and Tips

When installing the Timken 222535 pinion seal, ensure the transmission housing bore and shaft are clean and free of debris. Use appropriate tools to press the seal evenly into the housing bore without damaging the sealing lip. Verify the helix direction matches the original seal orientation to maintain proper fluid flow and sealing performance. It is recommended to inspect the shaft surface for wear or damage before installation to prevent premature seal failure.

Quality Assurance and Warranty

Timken manufactures the 222535 pinion seal to meet strict quality standards, ensuring reliable performance in automotive transmission applications. While specific warranty details are not provided, Timken products are generally backed by the brand's commitment to durability and precision engineering. For best results, use this seal as a direct replacement part for compatible Audi, Chevrolet, Lexus, Suzuki, Toyota, and Volkswagen models.
