Timken 223014 Manual Transmission Output Shaft Seal - Front or Rear

Manual Transmission Output Shaft Seal for Timken 223014

Timken 223014 is a manual transmission output shaft seal built for precise lubricant control in a wide range of import and domestic applications. It uses an S-Nitrile sealing material, a reinforced outer case, and a ribbed inner diameter to help maintain a secure seal on the shaft.

Compatible With applications such as Mitsubishi Lancer, Hyundai Tucson, Ford Ranger, and Isuzu Rodeo, this seal is designed for manual transmission service where shaft sealing and contamination control matter. The Timken 223014 part number is also referenced across multiple aftermarket listings for the same application.

Key Features

• S-Nitrile construction for sealing performance in transmission service
• Reinforced outer case helps resist installation damage and improve durability
• Ribbed rubber inner diameter helps seal minor spindle imperfections and support positive seating
• Internal contamination exclusion system helps block debris that can lead to leakage
• Vent holes promote lubricant flow around the seal lip to help reduce heat build-up
• Dimensions: 1.781 in. outside diameter, 1.181 in. shaft diameter, 1.772 in. housing bore, 0.236 in. width

Detailed Description

Timken 223014 is a manual transmission output shaft seal engineered for dependable sealing at the transmission output shaft. The seal’s S-Nitrile material is paired with a reinforced outer case and a ribbed inner diameter to help maintain contact on the shaft and support a stable fit in the housing bore. Its contamination exclusion design helps reduce debris intrusion, while vent holes allow lubricant circulation around the seal lip to manage heat during operation. This part number is commonly used in manual transmission applications across Mitsubishi, Hyundai, Ford, Isuzu, Dodge, and Plymouth vehicles, including Mitsubishi Lancer, Ford Ranger, and Isuzu Rodeo platforms.

This part cross-references National 223014 for the same application.

What It Helps Address

• Transmission fluid leakage at the output shaft
• Contamination entering the seal area
• Wear from minor shaft surface imperfections
• Heat-related seal deterioration
• Poor sealing performance after service or rebuild work

Installation Notes and Tips

Verify shaft diameter, housing bore, and width before installation. Clean the sealing surface and housing thoroughly, and inspect the shaft for grooves, corrosion, or burrs that could affect sealing. Press the seal in evenly to avoid distorting the reinforced case, and confirm the lip seats squarely on the shaft. For fitment, this seal is listed for applications including Fits 2001-2011 Ford Ranger, rear; Fits 2000-2004 Isuzu Rodeo, front; and Fits 2008-2015 Mitsubishi Lancer, N/A.

Quality Assurance

Timken manufactures oil and grease seals with precision sealing designs intended to control lubricant escape and keep contaminants out of the assembly. The reinforced case, ribbed sealing edge, and contamination exclusion features support consistent service in manual transmission use.
