Timken 223552 Manual Transmission Output Shaft Seal - Left or Right

Reliable Manual Transmission Output Shaft Seal for Chevrolet and Suzuki

The Timken 223552 manual transmission output shaft seal is engineered to provide durable sealing performance for select Chevrolet and Suzuki models. Designed with precision dimensions and high-quality S-nitrile material, this seal helps maintain transmission integrity and prevent fluid leaks.

• Constructed from durable S-nitrile material for resistance to heat and wear
• Outside diameter measures 2.452 inches (62.28 mm) ensuring a precise fit
• Shaft diameter of 1.378 inches (35.00 mm) matches OEM specifications
• Housing bore dimensions of 2.441 inches (62.00 mm) for secure installation
• Seal width of 0.276 inches (7.00 mm) designed for optimal sealing pressure

Detailed Product Description

The Timken 223552 output shaft seal is specifically designed for manual transmissions in Chevrolet and Suzuki vehicles, including models such as the Esteem, Forsa, Metro, Spark, Sprint, and Swift. Manufactured from S-nitrile, a synthetic rubber known for its excellent resistance to petroleum-based fluids and high temperatures, this seal ensures long-lasting performance under demanding conditions. The precise outside diameter of 2.452 inches (62.28 mm) and shaft diameter of 1.378 inches (35.00 mm) provide a tight fit to prevent transmission fluid leakage. Additionally, the housing bore size of 2.441 inches (62.00 mm) and a width of 0.276 inches (7.00 mm) contribute to a secure and reliable seal within the transmission assembly.

Common Applications and Issues Addressed

• Prevents manual transmission fluid leaks on Chevrolet and Suzuki models
• Reduces risk of contamination entering the transmission system
• Helps maintain proper lubrication of the output shaft
• Addresses wear-related seal failures due to heat and friction
• Supports smooth transmission operation by maintaining fluid integrity

Installation Notes and Tips

• Ensure the transmission output shaft and housing bore are clean and free of debris before installation
• Use appropriate tools to avoid damaging the seal during installation
• Verify dimensions match OEM specifications for the specific vehicle model
• Apply a light coating of transmission fluid to the seal lip to ease installation
• Inspect the seal for any defects prior to installation to ensure proper function

Quality Assurance and Warranty

Timken manufactures the 223552 output shaft seal to meet stringent quality standards, ensuring reliable performance in manual transmission applications. The use of S-nitrile material provides resistance to heat, oil, and wear, contributing to the seal's durability. While specific warranty details may vary, Timken products typically come with a limited warranty against manufacturing defects, providing confidence in the product's quality and longevity.
