TrakMotive FD-8143 CV Axle Shaft - Front Left
| Brand | TrakMotive FD-8143 |
|---|---|
| Position | Front Left |
| Abs Ring Tooth Count | 44 |
| Abs Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | 5/6 |
| Axle Nut Height (mm) | 21.2 |
| Axle Nut Hex Size (in) | 1 1/4 |
| Axle Nut Hex Size (mm) | 31.8 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1 1/3 |
| Axle Nut Length (mm) | 34.4 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M22*1.5 |
| Boot Material | Neoprene |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number Of Inboard Splines | 30 |
| Number Of Outboard Splines | 28 |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 22.64 |
| Overall Compressed Length (mm) | 575 |
| Product line | CV Axle Shaft |
| Fits | Ford and Mazda · 14 vehicles |
OE-style replacement. New CV axle shaft with included axle nut and tone ring.
Neoprene boot. Helps resist wear while keeping the joint protected.
ABS-ready design. Toothed ring and tone ring are included for sensor compatibility.
Cross-references Cardone New 66-2183, Dixie Electric Ltd 11933 and TrakMotive FD-8143 for the same application. See all 16.
CV Axle Shaft for Ford Escape and Mazda Tribute
TrakMotive FD-8143 is a new CV axle shaft for front left applications on select Ford Escape and Mazda Tribute models. It is built with a neoprene boot, a toothed ABS ring with 44 teeth, and a supplied axle nut for a direct replacement-style service part.
Key Features
- Brand: TrakMotive CV Axle Shaft
- Part number: FD-8143
- Front left position
- New construction
- Neoprene boot material
- Inboard shaft connection style: male
- Outboard shaft connection style: conventional
- 30 inboard splines and 28 outboard splines
- Overall compressed length: 22.64 in. (575 mm)
- ABS tone ring included with 44-tooth toothed ring
- Axle nut included, M22 x 1.5 self-lock design
Product Details
The TrakMotive FD-8143 CV axle shaft is engineered for front left driveline service on 2005-2006 Ford Escape, 2007-2012 Ford Escape, and 2005-2006 Mazda Tribute, plus 2008-2011 Mazda Tribute applications. It also includes an inboard guide tool for the listed fitments. TrakMotive identifies this axle as a new part built under ISO 9001:1007 and TS 16949:2009 certified manufacturing standards, with ABS axle coverage that fits non-ABS applications unless otherwise noted.
This part cross-references Cardone New 66-2183 for the same application. Search terms such as Ford Escape front left CV axle shaft FD-8143 and Mazda Tribute front left axle replacement FD-8143 can help narrow the correct driveline component for your vehicle.
What It Helps Fix
- Clicking or popping during turns from a worn CV joint
- Vibration or shudder under acceleration
- Grease leakage from a damaged axle boot
- ABS warning concerns related to a damaged tone ring assembly
- Driveline noise caused by excessive axle wear
Installation Notes
Verify spline count, compressed length, and axle nut thread size before installation. Confirm front left placement and match the vehicle’s ABS or non-ABS configuration to the application notes. Use the included axle nut and follow the manufacturer service procedure for torque and final inspection.
Quality Assurance
TrakMotive backs this CV axle shaft with a limited lifetime warranty. The brand also notes ISO 9001:1007 and TS 16949:2009 certified production, supporting consistent manufacturing control for the FD-8143 replacement axle.
| Year | Make | Model | Drive Type | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2012 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2011 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2011 | Mazda | Tribute | 4WD | Manual | 2.5L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2010 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2010 | Mazda | Tribute | 4WD | Manual | 2.5L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2009 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2009 | Mazda | Tribute | 4WD | Manual | 2.5L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2008 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2008 | Mazda | Tribute | 4WD | Manual | 2.3L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2007 | Ford | Escape | 4WD | Manual | — | — | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2006 | Ford | Escape | 4WD | Manual | 2.3L | L4 | Front Left | Includes Inboard Guide Tool; VIN Z (8th Digit); CV Axle Shaft |
| 2006 | Mazda | Tribute | AWD | Manual | 2.3L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
| 2005 | Ford | Escape | 4WD | Manual | 2.3L | L4 | Front Left | Includes Inboard Guide Tool; VIN Z (8th Digit); CV Axle Shaft |
| 2005 | Mazda | Tribute | AWD | Manual | 2.3L | L4 | Front Left | Includes Inboard Guide Tool; CV Axle Shaft |
