TrakMotive FD-8145 CV Axle Shaft - Front Left

Overview of TrakMotive CV Axle Shaft FD-8145

The TrakMotive CV Axle Shaft FD-8145 is engineered for reliable driveline performance in Ford Escape and Mercury Mariner vehicles. Designed to meet OEM specifications, this new CV axle shaft ensures consistent power transfer and durability for your vehicle's front-wheel or all-wheel drive system.

• Compatible with Ford Escape and Mercury Mariner models
• Includes a self-locking hex axle nut (M22*1.5 thread size)
• Equipped with a 44-tooth ABS tone ring for accurate wheel speed sensing
• Neoprene boot material for enhanced joint protection
• Overall compressed length of 25.87 inches (657 mm)

TrakMotive CV Axle Shaft Product Line Details

The TrakMotive CV Axle Shaft product line focuses on delivering precision-engineered constant velocity components that maintain driveline integrity and vehicle safety. This line includes shafts with specific ABS ring configurations and durable boot materials, such as neoprene, to withstand harsh driving conditions. The FD-8145 model exemplifies this approach by integrating a toothed ABS ring and a self-locking axle nut to ensure secure installation and reliable operation.

Technical Specifications and Features

This CV axle shaft features a male inboard joint type with 35 splines and a conventional outboard joint with 28 splines, providing a secure connection to the drivetrain. The included axle nut has a hex head measuring 1 1/4 inches (32 mm) across flats, with a height of 20 mm (4/5 inch) and a length of 37 mm (1 1/2 inch). The neoprene boot material offers resistance to wear and environmental factors, extending the life of the joint. The ABS tone ring is toothed with 44 teeth, included to support the vehicle's anti-lock braking system functionality.

Applications and Problem Solving

• Replacement for worn or damaged CV axle shafts on Ford Escape and Mercury Mariner
• Restores proper ABS sensor function with included toothed ABS tone ring
• Eliminates axle vibration and noise caused by joint wear
• Prevents grease leakage and contamination with durable neoprene boots
• Ensures secure wheel attachment with self-locking axle nut

Installation Notes and Tips

When installing the TrakMotive CV Axle Shaft FD-8145, verify compatibility with your specific Ford Escape or Mercury Mariner model year. Use the included self-locking hex axle nut (M22*1.5 thread) and torque to manufacturer specifications to ensure proper fitment and safety. Inspect the ABS tone ring alignment carefully to maintain accurate wheel speed sensor readings. It is recommended to replace axle components in pairs to maintain balanced driveline performance.

Quality Assurance and Warranty

The TrakMotive CV Axle Shaft FD-8145 is a new, not remanufactured, component built to meet or exceed OEM standards. It includes a self-locking axle nut and is constructed with high-quality materials such as neoprene boots for durability. While specific warranty details are not provided, TrakMotive products typically adhere to industry quality controls to ensure reliable service life.
