TrakMotive FD-8338 CV Axle Shaft - Front Right

Overview of TrakMotive CV Axle Shaft FD-8338 for Ford Fiesta

The TrakMotive CV Axle Shaft FD-8338 is designed specifically for Ford Fiesta models, providing reliable driveline performance. This new CV axle shaft ensures proper fitment and durability for your vehicle's front-wheel-drive system.

• Compatible with Ford Fiesta vehicles
• Includes self-locking axle nut with hex head
• Neoprene boot material for enhanced joint protection
• Inboard joint type: Male with 26 splines
• Outboard joint type: Conventional with 25 splines
• Overall compressed length: 36.38 inches (924 mm)
• Axle nut thread size: M22 x 1.5
• Axle nut dimensions: 1.25 inch (31.8 mm) hex size, 0.74 inch (18.9 mm) height

TrakMotive CV Axle Shaft Product Line Details

The TrakMotive CV Axle Shaft product line focuses on delivering precise driveline components engineered for specific vehicle applications. This line emphasizes quality materials and accurate fitment, such as the neoprene boot and spline connection styles found in the FD-8338, to maintain drivetrain integrity and reduce premature wear.

Technical Description and Features

The FD-8338 CV axle shaft features a neoprene boot that offers resistance to environmental elements, helping to protect the constant velocity joints from dirt and moisture. The inboard joint is a male type with 26 splines, while the outboard joint is conventional with 25 splines, both designed for secure spline engagement. The included axle nut is self-locking with a hex head measuring 1.25 inches across flats and a thread size of M22 x 1.5, ensuring a secure fit during installation. The overall compressed length of 36.38 inches (924 mm) matches OEM specifications for proper driveline geometry on Ford Fiesta models.

Common Applications and Problem Solving

• Replacement for worn or damaged CV axle shafts on Ford Fiesta
• Eliminates clicking or popping noises during turns caused by joint wear
• Resolves vibration issues related to axle imbalance or joint failure
• Prevents grease leaks from torn or degraded CV boots
• Restores proper driveline function after axle shaft bending or damage

Installation Notes and Tips

Ensure the vehicle is securely lifted and supported before beginning installation. Verify that the axle nut thread size (M22 x 1.5) matches the hub assembly. Use the included self-locking hex head axle nut (1.25 inch) and torque to manufacturer specifications. Inspect the splines on both the inboard and outboard shafts for damage before installation. Properly seat the neoprene boot to prevent contamination and premature joint failure.

Quality Assurance and Warranty

The TrakMotive CV Axle Shaft FD-8338 is a new, not remanufactured, component built to meet or exceed OEM standards. It undergoes quality control inspections to ensure fitment accuracy and durability. While specific warranty details are not provided, TrakMotive products typically come with a limited warranty against defects in materials and workmanship.
