TrakMotive SK-8058 CV Axle Shaft - Front Left

Overview of TrakMotive CV Axle Shaft SK-8058 for Suzuki Forenza

The TrakMotive CV Axle Shaft SK-8058 is engineered specifically for Suzuki Forenza models, providing reliable driveline performance. Designed as a new replacement part, this axle shaft ensures proper fit and function for your vehicle's front-wheel drive system.

• Compatible with Suzuki Forenza vehicles
• Includes a neoprene boot for durability and protection
• Equipped with a 47-tooth ABS ring and included tone ring
• Features a hex head axle nut with stake locking type
• Overall compressed length of 23.15 inches (588 mm)

TrakMotive CV Axle Shaft Product Line Details

The TrakMotive CV Axle Shaft product line focuses on delivering precise driveline components tailored to specific vehicle applications. This line emphasizes quality materials such as neoprene boots and includes essential hardware like axle nuts with stake locking to ensure secure installation. The SK-8058 model exemplifies this approach by combining durability with exact fitment for Suzuki Forenza models.

Technical Specifications and Features

This CV axle shaft features a male inboard joint type with 34 splines and a conventional outboard joint with 33 splines, designed to match the original equipment specifications. The ABS ring is a toothed type with 47 teeth and includes the ABS tone ring for proper sensor operation. The axle nut is a hex head type measuring 30 mm (1 1/6 inch) across flats, with a length of 34.6 mm (1 1/3 inch) and a height of 21.5 mm (6/7 inch). It uses an M20x1.5 thread size and a stake locking mechanism to prevent loosening during operation. The boot material is neoprene, chosen for its resistance to wear and environmental factors.

Common Applications and Problem Resolution

• Replacement for worn or damaged CV axle shafts on Suzuki Forenza
• Restores proper ABS sensor function with included tone ring
• Eliminates axle vibration caused by joint wear or boot failure
• Prevents grease leakage with durable neoprene boot
• Secures wheel hub connection with included stake-lock axle nut

Installation Notes and Tips

When installing the TrakMotive CV Axle Shaft SK-8058, ensure the axle nut is torqued to manufacturer specifications and properly staked to prevent loosening. Verify the ABS tone ring is correctly positioned to maintain accurate sensor readings. Inspect the neoprene boot for any damage during installation to avoid premature failure. This axle shaft is designed for direct replacement on Suzuki Forenza models, so no modifications should be necessary.

Quality Assurance and Warranty

The TrakMotive CV Axle Shaft SK-8058 is a new, remanufactured-quality part built to meet or exceed OEM standards. It includes all necessary hardware such as the axle nut and ABS tone ring for a complete replacement solution. While specific warranty details are not provided, TrakMotive products typically undergo rigorous quality control to ensure durability and reliable performance in driveline applications.
