TYC 13080 Radiator - Primary
| Brand | TYC 13080 |
|---|---|
| Position | Primary |
| Core Material | Aluminum |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Plate oil cooler |
| Engine Oil Cooler Included | No |
| Bottom Header | 2.87x28.82 |
| Core Height (in) | 27.99 |
| Core Length (in) | 23.27 |
| Core Thickness (in) | 1.89 |
| Fin Count (every 4") | 60 |
| Fin Wave Height (in) | 0.31 |
| Find Wave Pitch | 3.4 |
| Flow Configuration | Downflow |
| Inlet Connection Type | Hose clamp |
| Inlet Diameter (in) | 1.50 |
| No. Of Rows | 1 |
| Outlet Connection Type | Hose clamp |
| Outlet Diameter (in) | 1.63 |
| Toc Distance (in) | 15.35 |
| Toc Inlet Diameter (in) | 0.39 |
| Toc Inlet Type | Tube fitting |
| Toc Outlet Diameter (in) | 0.39 |
| Toc Outlet Type | Tube fitting |
| Top Header | 2.87x28.82 |
| Total Fin Row Count | 75 |
| Total Tube Count | 74 |
| Tube Count (every 4") | 10 |
| Tube Width X Height | 22x2 |
| Product line | TYC Radiator |
| Fits | Lexus and Toyota · 26 vehicles |
Aluminum core. Lightweight construction helps promote efficient heat transfer.
Transmission oil cooler included. Adds integrated cooling for the transmission fluid circuit.
Hose clamp connections. Simplifies hose attachment for a secure, straightforward install.
Cross-references APDI 8013080, DENSO 221-3153 and Partslink TO3010326 for the same application. See all 7.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
TYC Radiator for Lexus LX570 and Toyota Land Cruiser
The TYC Radiator Part Number 13080 is a direct-fit cooling system replacement for select Lexus LX570 and Toyota Land Cruiser applications. Built with an aluminum core and a downflow design, it includes a transmission oil cooler with plate-style construction for vehicles that use integrated automatic transmission cooling.
Key Features
- Aluminum core construction for efficient heat transfer
- Downflow radiator layout
- Transmission oil cooler included
- Plate oil cooler type
- Hose clamp inlet and outlet connections
- Core dimensions: 27.99 in height, 23.27 in length, 1.89 in thickness
- Single-row core design with 74 tubes and 75 total fin rows
- Inlet diameter: 1.50 in; outlet diameter: 1.63 in
Product Details
TYC Radiator Part Number 13080 is engineered for cooling-system service on 2008-2011 Lexus LX570 and Toyota Land Cruiser, as well as 2013-2021 Lexus LX570 and Toyota Land Cruiser applications. The radiator uses an aluminum core with a downflow flow configuration and integrated transmission oil cooler connections, making it a practical replacement for vehicles that rely on combined engine and transmission temperature control. This part cross-references DENSO 221-3153 for the same application.
The TYC Radiator line focuses on replacement cooling components built to match OE-style fitment and connection points. For Lexus LX570 and Toyota Land Cruiser owners, Part Number 13080 provides the core dimensions, hose clamp fittings, and cooler layout needed for a straightforward radiator replacement in supported vehicles.
Common Issues This Radiator Can Address
- Coolant leaks from a damaged or corroded radiator
- Overheating caused by restricted or failing radiator flow
- Transmission temperature concerns related to a worn cooler circuit
- Cracked plastic end tanks or weakened core seams
- Reduced cooling efficiency from age, debris, or internal blockage
Installation Notes and Tips
Verify radiator dimensions, inlet and outlet sizes, and transmission cooler line routing before installation. Confirm the vehicle uses hose clamp-style upper and lower connections and compare the existing cooler fittings to the tube-fitting style listed for the transmission oil cooler. Flush the cooling system, inspect hoses and clamps, and refill with the correct coolant specification after installation. Fits 2008-2011 Lexus LX570, N/A. Fits 2008-2011 Toyota Land Cruiser, N/A. Fits 2013-2021 Lexus LX570, Primary. Fits 2013-2021 Toyota Land Cruiser, Primary.
Quality Assurance
TYC manufactures replacement cooling components with application-specific dimensions and connection points for supported Lexus and Toyota vehicles. Part Number 13080 is listed with confirmed fitment for the model years shown above and is built to match the radiator and transmission cooler configuration required by those applications.
| Year | Make | Model | Submodel | Body Type | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|---|
| 2021 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2021 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2020 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2020 | Toyota | Land Cruiser | Heritage Edition | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2019 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2019 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2018 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2018 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2017 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2017 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2016 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2016 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2015 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2015 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2014 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2014 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2013 | Lexus | LX570 | — | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2013 | Toyota | Land Cruiser | Base | Sport Utility | — | 5.7L | V8 | Primary | TYC Radiator |
| 2011 | Lexus | LX570 | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2011 | Toyota | Land Cruiser | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2010 | Lexus | LX570 | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2010 | Toyota | Land Cruiser | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2009 | Lexus | LX570 | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2009 | Toyota | Land Cruiser | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2008 | Lexus | LX570 | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
| 2008 | Toyota | Land Cruiser | — | — | Automatic | 5.7L | V8 | N/A | TYC Radiator |
