TYC 13202 Radiator

Overview of TYC Radiator 13202 for Hyundai Elantra

The TYC Radiator 13202 is engineered specifically for Hyundai Elantra models, providing reliable cooling performance. Designed with durable aluminum core and plastic tanks, this radiator supports efficient engine temperature regulation and transmission oil cooling.

• Core material constructed from aluminum for effective heat dissipation
• Plastic tank material to reduce weight and resist corrosion
• Concentric transmission oil cooler integrated for optimal fluid cooling
• Crossflow design enhances coolant flow and heat exchange
• Core dimensions: 16.22 inches height, 21.77 inches length, 0.63 inches thickness
• Inlet and outlet diameters sized at 1.39 and 1.30 inches respectively with hose clamp fittings
• Single-row core with fin height of 0.21 inches for balanced airflow
• Transmission oil cooler fittings spaced 11.02 inches apart with hose clamp design

TYC Radiator Product Line Details

The TYC Radiator product line focuses on delivering replacement radiators that meet or exceed OEM specifications. This line emphasizes quality materials such as aluminum cores and plastic tanks to ensure durability and efficient cooling. The TYC Radiator 13202 is part of this line, designed to maintain proper engine and transmission temperatures for Hyundai Elantra vehicles.

Technical Description and Specifications

This radiator features a crossflow flow configuration, which allows coolant to pass horizontally through the core, improving heat transfer efficiency. The aluminum core measures 16.22 inches in height, 21.77 inches in length, and 0.63 inches in thickness, providing a robust cooling surface. The single-row core design with a fin height of 0.21 inches supports effective airflow. Both inlet and outlet ports use hose clamp fittings, with diameters of 1.39 inches and 1.30 inches respectively, ensuring secure hose connections. The integrated concentric transmission oil cooler has inlet and outlet diameters of 0.39 inches, also equipped with hose clamp fittings, spaced 11.02 inches apart to fit Hyundai Elantra transmission lines precisely.

Common Applications and Problem Resolution

• Replacement for leaking or damaged radiators in Hyundai Elantra models
• Solves overheating issues caused by inefficient cooling systems
• Addresses transmission fluid overheating with integrated oil cooler
• Prevents coolant leaks from cracked or corroded plastic tanks
• Restores proper coolant flow and engine temperature regulation

Installation Notes and Tips

When installing the TYC Radiator 13202, ensure all hose clamp fittings are securely tightened to prevent leaks. Verify that the transmission oil cooler lines align with the concentric fittings spaced 11.02 inches apart. Properly bleed the cooling system after installation to remove air pockets and maintain optimal performance. This radiator is designed for direct replacement in compatible Hyundai Elantra models, so no modifications should be necessary.

Quality Assurance and Warranty

TYC Radiator 13202 is manufactured to meet industry standards for durability and performance. The aluminum core and plastic tank materials are selected to resist corrosion and wear. While specific warranty details are not provided, TYC products typically undergo rigorous quality control to ensure reliability in automotive cooling applications.
