TYC 13333 Radiator - Primary

Overview of TYC Radiator 13333 for Hyundai and Kia Vehicles

The TYC Radiator 13333 is engineered to provide reliable cooling performance for select Hyundai and Kia models. Designed with an aluminum core and integrated transmission oil cooler, this radiator supports efficient engine temperature management and transmission fluid cooling.

• Core material constructed from durable aluminum for effective heat dissipation
• Includes a concentric transmission oil cooler for enhanced transmission fluid cooling
• Crossflow design with 1.94x16.18 inch top and bottom headers
• Core dimensions: 15.55 inches height, 21.73 inches length, and 0.63 inches thickness
• Single-row tube configuration with 60 tubes and 85 fins per 4 inches for optimized airflow
• Hose clamp inlet and outlet connections with 1.38 inch diameter
• Compatible with Hyundai Elantra, Elantra Coupe, Kia Forte, Forte5, Forte Koup, and Soul models

TYC Radiator Product Line Details

The TYC Radiator product line focuses on delivering quality cooling components that meet or exceed OEM specifications. Radiators in this line, including part number 13333, are designed with precision to ensure proper fitment and reliable performance in specific vehicle applications. The inclusion of a concentric transmission oil cooler in this model highlights TYC's attention to integrated cooling solutions for both engine and transmission systems.

Technical Specifications and Features

This radiator features a crossflow core design that promotes efficient coolant flow across the core, improving heat exchange. The aluminum core material enhances thermal conductivity while maintaining lightweight construction. The core measures 15.55 inches in height, 21.73 inches in length, and 0.63 inches in thickness, with a single row of 60 tubes and 85 fins per 4 inches to maximize cooling surface area. Both the inlet and outlet connections use hose clamps with a diameter of 1.38 inches, ensuring secure hose attachment. The integrated concentric transmission oil cooler uses tube fittings with 0.39 inch inlet and outlet diameters, supporting transmission fluid cooling without the need for a separate cooler.

Compatible Vehicles and Common Applications

• Replacement radiator for Hyundai Elantra and Elantra Coupe models
• Suitable for Kia Forte, Forte5, and Forte Koup vehicles
• Compatible with Kia Soul models requiring integrated transmission oil cooling
• Addresses overheating issues caused by radiator core damage or clogging
• Resolves transmission fluid temperature regulation problems in vehicles with integrated coolers

Installation Notes and Tips

When installing the TYC Radiator 13333, ensure all hose clamps are securely fastened to prevent leaks. Verify that the transmission oil cooler connections are properly fitted using the tube fittings provided. It is recommended to flush the cooling system before installation to remove debris and contaminants. Check for proper coolant levels and inspect hoses for wear or damage during replacement.

Quality Assurance and Warranty

TYC Radiator 13333 is manufactured to meet industry standards for durability and performance. The aluminum core construction and integrated transmission oil cooler are designed for long service life. While specific warranty details are not provided here, TYC products typically come with a limited warranty against defects in materials and workmanship. Consult product documentation or the manufacturer for exact warranty terms.
