TYC 150397-A Fuel Pump Module Assembly

Fuel Pump Module for Honda CR-V

TYC CRQ Premium Fuel Pump Module 150397-A is a direct-fit fuel pump module assembly for select 2012-2014 Honda CR-V models. It is built around the key service parts needed for fuel delivery and tank sealing, with OE-style connections and sensor specifications that match the application.

The TYC CRQ Premium Fuel Pump Module line focuses on replacement fuel system components engineered for accurate fitment and dependable fuel delivery. For Honda CR-V service, this module supports the fuel tank assembly with the included O-ring and fuel tank gasket, along with a quick connector fuel tube connection and a 4-pin main connector.

Key Features

• Fits 2012-2014 Honda CR-V, N/A
• TYC CRQ Premium Fuel Pump Module 150397-A
• Fuel level sensor resistance range: 20 - 780 Ohms
• Fuel tube connection type: quick connector
• Main connector: 4 pins
• Fuel tank gasket included
• Accessories included: O-ring
• Fuel flow rating: 26.3 GPH
• Maximum air pressure: 331 kPa

Detailed Description

This fuel pump module assembly is intended for the fuel delivery system in the 2012, 2013, and 2014 Honda CR-V. The module includes the fuel tank gasket and an O-ring, and it uses a quick connector fuel tube connection for service-friendly installation. The 4-pin main connector and 20 - 780 Ohms fuel level sensor resistance range support proper electrical and gauge-system integration for the vehicle application. Part number 150397-A is also a useful reference when sourcing the correct replacement for this Honda CR-V fuel pump module.

This part cross-references Airtex E9186M and Honda 17045-T0A-010 for the same application.

What It Helps Address

• Hard starting caused by weak fuel delivery
• Fuel starvation under load or during acceleration
• Inaccurate fuel level readings from a worn module
• Fuel odor or seepage at the tank module seal
• Intermittent pump operation related to connector or module wear

Installation Notes and Tips

Verify the connector style, fuel tube quick connection, and tank opening before installation. Replace the module only after confirming the vehicle is a 2012-2014 Honda CR-V and that the existing fuel system configuration matches the listed application. Clean the tank sealing surface before installing the included gasket and O-ring to help ensure a proper seal. After installation, cycle the ignition and inspect for leaks and correct fuel gauge operation.

Quality Assurance

TYC CRQ Premium fuel system components are built for application-specific replacement service, with fitment and connector details matched to the listed vehicle platform. Part number 150397-A is specified for select Honda CR-V fuel pump module replacement needs.
