TYC 150409-A Fuel Pump Module Assembly

Overview of the TYC CRQ Premium Fuel Pump Module for Toyota Camry

The TYC CRQ Premium Fuel Pump Module Assembly (Part Number 150409-A) is designed specifically for Toyota Camry models, providing reliable fuel delivery and accurate fuel level readings. This module includes essential components to ensure proper installation and optimal performance.

• Includes strainer for fuel filtration
• Seal ring and fuel tank gasket included for secure sealing
• Four-pin main connector for reliable electrical connection
• Fuel level sensor resistance range from 15 to 415 ohms
• Buckle type fuel tube connection for easy installation
• Fuel flow rate of 23.6 gallons per hour (gph)
• Maximum air pressure rating of 331 kPa

Detailed Features and Specifications

The TYC CRQ Premium Fuel Pump Module Assembly (150409-A) is engineered to meet the fuel delivery requirements of Toyota Camry vehicles. The included strainer helps prevent contaminants from entering the fuel system, protecting the engine and fuel injectors. The seal ring and fuel tank gasket ensure a tight, leak-free fit within the fuel tank assembly. The four-pin connector provides a secure electrical interface, supporting the fuel pump and fuel level sensor functions.

The fuel level sensor operates within a resistance range of 15 to 415 ohms, allowing accurate fuel gauge readings. The buckle type connection for the fuel tube simplifies installation and maintenance. With a fuel flow capacity of 23.6 gallons per hour, this module supports efficient fuel delivery under various driving conditions. The maximum air pressure rating of 331 kPa ensures the module can withstand typical fuel system pressures.

About the TYC CRQ Premium Fuel Pump Module Line

The TYC CRQ Premium Fuel Pump Module line focuses on providing high-quality fuel pump assemblies that combine durability and precise fitment. This product line is designed to meet or exceed OEM specifications, offering components such as integrated strainers, gaskets, and connectors to facilitate straightforward installation and reliable operation. The 150409-A part is a representative example tailored for Toyota Camry models, ensuring compatibility and performance.

Common Applications and Problem Resolution

• Replacement for failing or noisy fuel pumps in Toyota Camry
• Fixes inaccurate fuel gauge readings due to faulty fuel level sensors
• Resolves fuel delivery issues causing engine hesitation or stalling
• Addresses fuel leaks by providing new seal ring and fuel tank gasket
• Improves overall fuel system reliability and efficiency

Installation Notes and Tips

When installing the TYC CRQ Premium Fuel Pump Module Assembly 150409-A, ensure the fuel tank is properly drained and depressurized before removal. Verify that the seal ring and fuel tank gasket are correctly positioned to prevent leaks. Connect the four-pin main connector securely and confirm the buckle type fuel tube connection is locked in place. It is recommended to inspect the fuel strainer for debris during installation and replace if necessary.

Quality Assurance and Warranty

TYC manufactures the CRQ Premium Fuel Pump Module Assembly to meet stringent quality standards, ensuring durability and consistent performance. This part is engineered to match OEM specifications for Toyota Camry vehicles. Warranty coverage details should be confirmed with the distributor or retailer, as they may vary.
