TYC 150448-A Fuel Pump Module Assembly
| Brand | TYC 150448-A |
|---|---|
| Strainer Included | No |
| Accessories Included | Yes |
| Connector Pins Qty On Main Connector | 4 |
| Fuel Level Sensor Resitance Range | 250-40 |
| Fuel Tank Gasket Included | Yes |
| Fuel Tube Connection Type | Buckle type connection |
| Gph (gallons Per Hour Flow) | 160±20 |
| Maximum Air Pressure | 0.414±0.02 |
| Fits | Chevrolet and GMC · 10 vehicles |
Direct replacement. Fuel pump module assembly for listed fuel delivery service applications.
Secure connections. Buckle-type fuel tube connection and 4-pin main connector.
Sealing included. Fuel tank gasket is included for installation at the tank interface.
Cross-references Carter P76740M, Delphi FG1056 and Spectra Premium SP6092M for the same application. See all 5.
Fuel Pump Module Assembly Overview
This TYC fuel pump module assembly is built for direct replacement applications on select Chevrolet Silverado 1500 and GMC Sierra 1500 trucks. It is identified by part number 150448-A and supports fuel delivery with the correct electrical and fuel line connection points for the listed fitments.
Key Features
- Fuel pump module assembly for air and fuel delivery service.
- Includes a fuel tank gasket for sealing at installation.
- Buckle-type fuel tube connection for secure line attachment.
- 4-pin main connector for the specified electrical interface.
- Fuel level sensor resistance range: 250-40.
- Rated flow: 160 ±20 GPH with maximum air pressure of 0.414 ±0.02.
- Strainer not included.
Detailed Description
TYC part number 150448-A is a fuel pump module assembly for 2009-2013 Chevrolet Silverado 1500 and 2009-2013 GMC Sierra 1500 applications with the listed 5' 8" box 1/2 ton configuration. The module is specified with a buckle-type fuel tube connection, a 4-pin main connector, and a fuel level sensor resistance range of 250-40. These details matter when replacing a worn fuel delivery module on a Silverado 1500 or Sierra 1500 because the electrical and fuel connection design must match the vehicle setup.
This part cross-references Carter (e.g., P76740M) and Delphi (e.g., FG1056) for the same application.
What It Is Used For
- Replacing a fuel pump module with inconsistent fuel delivery.
- Addressing hard-start or no-start conditions related to fuel supply.
- Restoring proper fuel level sensor operation when gauge readings are inaccurate.
- Correcting fuel pressure or flow issues tied to a failing module.
Installation Notes and Tips
Verify the truck configuration before ordering, including the 5' 8" box 1/2 ton application listed in the fitment data. Confirm the 4-pin connector, buckle-type fuel tube connection, and fuel tank gasket requirements match the original setup. Part number 150448-A should be matched to the vehicle by fitment and connection style before installation.
Quality Assurance
TYC supplies replacement components for fuel system service, and this module is built to match the listed application details for fitment-sensitive replacement work.
| Year | Make | Model | Submodel | Body Type | Liters | Cylinders | Notes |
|---|---|---|---|---|---|---|---|
| 2013 | Chevrolet | Silverado 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2013 | GMC | Sierra 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2012 | Chevrolet | Silverado 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2012 | GMC | Sierra 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2011 | Chevrolet | Silverado 1500 | LS | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2011 | GMC | Sierra 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2010 | Chevrolet | Silverado 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2010 | GMC | Sierra 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2009 | Chevrolet | Silverado 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
| 2009 | GMC | Sierra 1500 | WT | Extended Cab Pickup | 4.3L | V6 | 5' 8" BOX 1/2 TON |
