TYC 17-5337-00-9 Reflector Assembly - Rear Right
| Brand | TYC 17-5337-00-9 |
|---|---|
| Position | Rear Right |
| Bulbs Included | Yes |
| Components Included | Complete Assembly |
| Housing Material | Plastic |
| Lens Color | Red |
| Lens Material | Plastic |
| Other Side | 17-5338-00-9 |
| Product line | CAPA Certified |
| Fits | Mazda · 12 vehicles |
CAPA certified. Meets recognized certification standards for dependable exterior lighting parts.
Complete assembly. Includes the reflector assembly components needed for a straightforward replacement.
Red lens. Plastic lens and housing provide a durable, lightweight construction.
Cross-references Mazda KD31-51-5L0 and Partslink MA2831101 for the same application. See all 2.
Rear Right Reflector Assembly for Mazda CX-5
This TYC CAPA Certified reflector assembly is built for the rear right position on select Mazda CX-5 models. It includes a red lens, plastic housing, and bulbs, providing a complete exterior lighting replacement for the rear of the vehicle.
Key Features
- TYC CAPA Certified reflector assembly
- Fits the rear right position
- Red lens with plastic lens material
- Plastic housing for exterior mounting
- Bulbs included
- Complete assembly for direct replacement
- Cross-reference: Mazda KD31-51-5L0
- Cross-reference: Partslink MA2831101
Product Details
Part number 17-5337-00-9 is a rear right reflector assembly for 2013-2016 Mazda CX-5 applications. As part of TYC’s CAPA Certified product line, this reflector assembly is built to match the specified vehicle application and restore the rear lighting reflector function on the Mazda CX-5. The red lens and plastic construction support a factory-style exterior appearance, while the complete assembly format simplifies replacement of the damaged or missing unit.
Fits 2013-2016 Mazda CX-5, rear right. This part number, 17-5337-00-9, is also referenced for the same application under Mazda KD31-51-5L0 and Partslink MA2831101.
Common Issues This Part Can Address
- Cracked or broken rear right reflector lens
- Faded or discolored reflector appearance
- Missing rear exterior reflector assembly
- Damage from minor impact or road debris
- Failed inspection due to visible rear lighting reflector damage
Installation Notes and Tips
Verify rear right position before installation and confirm the part matches the vehicle’s existing reflector layout. Inspect the mounting area for damage or debris before securing the complete assembly. For Mazda CX-5 replacement work, compare the original unit to part number 17-5337-00-9 and confirm the opposite-side reference, 17-5338-00-9, if needed for identification.
Quality Assurance
TYC CAPA Certified parts are built to meet recognized certification standards for fit and performance in the specified application. This reflector assembly is intended for 2013-2016 Mazda CX-5 rear right replacement use.
| Year | Make | Model | Submodel | Body Type | Position | Notes |
|---|---|---|---|---|---|---|
| 2016 | Mazda | CX-5 | Grand Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2016 | Mazda | CX-5 | Sport | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2016 | Mazda | CX-5 | Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2015 | Mazda | CX-5 | Grand Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2015 | Mazda | CX-5 | Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2015 | Mazda | CX-5 | Sport | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2014 | Mazda | CX-5 | Grand Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2014 | Mazda | CX-5 | Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2014 | Mazda | CX-5 | Sport | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2013 | Mazda | CX-5 | Grand Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2013 | Mazda | CX-5 | Sport | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
| 2013 | Mazda | CX-5 | Touring | Sport Utility | Rear Right | Components Included: Complete Assembly; Other Side: 17-5338-00-9; CAPA Certified |
