Will it fit your vehicle?
Confirm before you buy. Free return shipping if it doesn't fit.
TYC 20-14305-00-9 Headlight Assembly - Right
| Brand | TYC 20-14305-00-9 |
|---|---|
| Position | Right |
| Bulb Type | Halogen |
| Bulbs Included | Yes |
| Components Included | Complete Assembly |
| Daytime Running Light Bulb Type | same as Low Beam |
| Front Side Marker Light Bulb Included | Included |
| Front Side Marker Light Bulb Type | LED |
| Front Signal Light Bulb Included | Included |
| Front Signal Light Bulb Type | same as Park Lamp |
| High Beam Bulb Included | YES |
| High Beam Bulb Type | Halogen |
| Housing Material | Plastic |
| Lens Color | Clear, Amber |
| Lens Material | Plastic |
| Low Beam Bulb Included | YES |
| Low Beam Bulb Type | H11/HB3 |
| Other Side | 20-14306-00-9 |
| Park Lamp Bulb Included | Included |
| Park Lamp Bulb Type | Halogen |
| Product line | CAPA Certified |
| Fits | Chevrolet · 8 vehicles |
CAPA Certified. Meets recognized certification standards for dependable lighting replacement.
Complete assembly. Includes bulbs and components for a ready-to-install headlight assembly.
Halogen lighting. Clear, amber lens and plastic construction deliver a clean, factory-style look.
Cross-references Chevrolet 42435940 and Partslink GM2503401 for the same application. See all 2.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Right Headlight Assembly for Chevrolet Trax
This TYC CAPA Certified headlight assembly is a direct replacement for the right side on select Chevrolet Trax models. It is built as a complete assembly with bulbs included, clear and amber lens styling, and halogen lighting components for a straightforward OE-style repair.
Key Features
- TYC CAPA Certified headlight assembly
- Fits the right side on Chevrolet Trax applications
- Complete assembly with bulbs included
- Clear and amber lens color with plastic lens and housing
- Halogen low beam, high beam, and park lamp lighting
- Front side marker light uses an included LED bulb
- Front signal light bulb included
- Low beam bulb type: H11/HB3
- Daytime running light bulb type matches the low beam
Detailed Description
Built for 2013-2014 Chevrolet Trax, right and 2015-2016 Chevrolet Trax, right, this headlight assembly restores the front lighting position with the correct fit and lighting layout. The TYC 20-14305-00-9 is designed as a complete replacement unit with the low beam, high beam, park lamp, front signal light, and front side marker light bulbs included, helping simplify the repair process. The CAPA Certified designation identifies this part as meeting CAPA certification requirements for fit and performance in the replacement lighting category. This part cross-references Chevrolet 42435940 and Partslink GM2503401 for the same application.
Common Repair Applications
- Cracked or clouded headlight lens on the right side
- Failed low beam, high beam, or park lamp lighting
- Broken housing or mounting damage from front-end impact
- Dim, uneven, or non-functioning front lighting on a Chevrolet Trax
- Replacement after moisture intrusion or lens discoloration
Installation Notes and Tips
Verify the vehicle is a Chevrolet Trax with right-side fitment before installation. Confirm bulb type and connector alignment against the original unit, and transfer any vehicle-specific aiming or adjustment settings after installation. The assembly uses plastic lens and housing materials, so handle it carefully during installation to avoid scratches or mounting damage.
Quality Assurance
TYC CAPA Certified lighting products are built for replacement applications where fit, function, and certification matter. This headlight assembly is engineered for the specified Chevrolet Trax model years and right-side position, with bulbs included for a complete lighting repair.
| Year | Make | Model | Submodel | Body Type | Position | Notes |
|---|---|---|---|---|---|---|
| 2016 | Chevrolet | Trax | LT | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2016 | Chevrolet | Trax | LTZ | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2016 | Chevrolet | Trax | LS | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2015 | Chevrolet | Trax | LT | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2015 | Chevrolet | Trax | LS | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2015 | Chevrolet | Trax | LTZ | Sport Utility | Right | Other Side: 20-14306-00-9; CAPA Certified |
| 2014 | Chevrolet | Trax | LS | Sport Utility | Right | CAPA Certified |
| 2013 | Chevrolet | Trax | LS | Sport Utility | Right | CAPA Certified |
