TYC 20-9030-00 Headlight Assembly - Left
| Brand | TYC 20-9030-00 |
|---|---|
| Position | Left |
| Bulbs Included | Yes |
| Lens Color | Clear |
| Bulb Type | Halogen |
| Lens Material | Pc plastic |
| Housing Material | Pp plastic |
| Components Included | Complete assembly |
| Configuration | W/ quad lamps |
| Front Side Marker Light Bulb Included | Yes |
| Front Side Marker Light Bulb Type | Halogen 3157na |
| Front Signal Light Bulb Included | Yes |
| Front Signal Light Bulb Type | Halogen 3157na |
| Hardware Included | No |
| High Beam Bulb Included | Yes |
| High Beam Bulb Type | Halogen hb3 |
| Low Beam Bulb Included | Yes |
| Low Beam Bulb Type | Halogen h11 |
| Other Side | 20-9029-00 |
| Park Lamp Bulb Included | Yes |
| Park Lamp Bulb Type | Halogen 3157na |
| Sae/dot Compliant | Yes |
| Product line | TYC Regular |
| Fits | Dodge and Ram · 10 vehicles |
Complete assembly. Includes the lighting components listed for a full headlight replacement.
Halogen lighting. Uses H11 low beam and HB3 high beam bulb types with clear lens construction.
SAE/DOT compliant. Built to meet listed exterior lighting compliance requirements.
Cross-references 68001485AI and CH2518135 for the same application. See all 2.
Headlight Assembly for Ram and Dodge Ram
This TYC Regular headlight assembly is a complete left-side replacement built for specific Ram and Dodge Ram applications. It includes the bulbs needed for the lighting functions listed in the product data and uses a clear lens with halogen lighting.
Key Features
- Complete headlight assembly with clear lens and halogen bulb setup
- Polycarbonate lens and polypropylene housing for exterior lighting use
- Includes low beam, high beam, park lamp, front signal, and front side marker bulbs
- SAE/DOT compliant for road-use lighting requirements
- TYC Regular line replacement part, part number 20-9030-00
Product Details
Built as a complete assembly, this headlight is configured with quad lamps and is specified for the left side. The unit uses halogen bulbs throughout, including H11 low beam, HB3 high beam, and 3157NA bulbs for the park lamp, front signal, and front side marker functions. The clear lens and plastic housing materials are selected for exterior lighting service, while SAE/DOT compliance supports proper lighting standards. This part number, 20-9030-00, is listed for Ram 1500, Ram 2500, Ram 3500, and Dodge Ram 1500 applications with the exact configurations shown in the fitment data.
Common Issues This Part Can Address
- Cracked or clouded headlight lens
- Dim or failed forward lighting output
- Broken housing from road debris or age
- Failed signal, park, or marker lamp function within the assembly
- Need for a direct replacement headlight assembly with the correct lamp configuration
Installation Notes
Fits 2011-2012 Ram 1500, left, w/ Quad Lamps; TYC Regular. Fits 2011-2012 Ram 2500, left, Code LME; TYC Regular. Fits 2011-2012 Ram 3500, left, Code LME; TYC Regular. Fits 2009-2010 Dodge Ram 1500, left, w/ Quad Lamps; TYC Regular. Fits 2010 Dodge Ram 2500, left, Code LME; TYC Regular. Fits 2010 Dodge Ram 3500, left, Code LME; TYC Regular. Verify the lamp configuration and side before ordering. Hardware is not listed as included in the product data.
Quality Assurance
TYC Regular replacement lighting is built to match the specified application details and compliance requirements in the catalog data. Part number 20-9030-00 is cross-referenced to 68001485AI and CH2518135 for the same application.
| Year | Make | Model | Body Type | Position | Notes |
|---|---|---|---|---|---|
| 2012 | Ram | 1500 | Standard Cab Pickup | Left | w/ Quad Lamps; TYC Regular |
| 2012 | Ram | 2500 | Extended Crew Cab Pickup | Left | Code LME; TYC Regular |
| 2012 | Ram | 3500 | Crew Cab Pickup | Left | Code LME; TYC Regular |
| 2011 | Ram | 1500 | Extended Cab Pickup | Left | w/ Quad Lamps; TYC Regular |
| 2011 | Ram | 2500 | Standard Cab Pickup | Left | Code LME; TYC Regular |
| 2011 | Ram | 3500 | Extended Crew Cab Pickup | Left | Code LME; TYC Regular |
| 2010 | Dodge | Ram 1500 | Crew Cab Pickup | Left | w/ Quad Lamps; TYC Regular |
| 2010 | Dodge | Ram 2500 | Standard Cab Pickup | Left | Code LME; TYC Regular |
| 2010 | Dodge | Ram 3500 | Crew Cab Pickup | Left | Code LME; TYC Regular |
| 2009 | Dodge | Ram 1500 | Crew Cab Pickup | Left | w/ Quad Lamps; TYC Regular |
