TYC 20-9658-90 Headlight Assembly - Left

Overview of TYC Regular Headlight Assembly for Lexus NX200t

The TYC Regular 20-9658-90 headlight assembly is designed specifically for the left side of the Lexus NX200t with the sport package. This complete lighting solution includes LED low beam bulbs and halogen high beam and side marker bulbs, providing reliable exterior illumination with clear and amber lens colors.

• Complete headlight assembly for left side of Lexus NX200t
• Includes LED low beam bulb and halogen high beam (HB3) bulb
• Front side marker light with halogen bulb included
• Clear and amber plastic lens for optimal visibility
• Durable plastic housing material
• Single beam configuration
• SAE/DOT compliant for road safety standards

Detailed Features and Specifications

The TYC Regular 20-9658-90 headlight assembly features a plastic lens and housing designed to withstand typical road conditions while maintaining clarity and durability. The assembly includes LED bulbs for the low beam, enhancing energy efficiency and longevity, while the high beam and front side marker lights use halogen bulbs for consistent brightness. This single beam configuration is tailored for the left side of the Lexus NX200t equipped with the sport package, ensuring proper fit and function. Note that hardware is not included, but the assembly comes complete with all necessary lighting components except the LED controller.

Compatible Vehicles and Fitment Details

This headlight assembly is compatible with the Lexus NX200t model, specifically for vehicles equipped with the sport package. The part number 20-9658-90 corresponds to the left side headlight, with the right side counterpart being 20-9657-90. Ensure compatibility by verifying your vehicle’s model and package before installation.

Common Issues Addressed by This Headlight Assembly

• Damaged or cracked headlight lens affecting visibility
• Burned out or malfunctioning low beam LED bulbs
• Non-functional high beam halogen bulbs
• Faulty front side marker light halogen bulbs
• Discolored or faded plastic housing and lens

Installation Notes and Tips

• Installation requires removal of the existing headlight assembly; hardware is not included
• Handle the LED and halogen bulbs carefully to avoid damage
• Verify alignment and secure fit to maintain proper beam pattern
• Consult vehicle service manual for detailed removal and installation procedures
• Check electrical connections for proper function after installation

Quality Assurance and Compliance

The TYC Regular 20-9658-90 headlight assembly meets SAE and DOT compliance standards, ensuring it adheres to safety and performance regulations for exterior vehicle lighting. Manufactured with quality plastic materials for both lens and housing, this assembly is built to provide consistent lighting performance. While hardware is not included, the complete assembly comes with all necessary bulbs for immediate replacement. Warranty information should be confirmed with the product supplier or manufacturer.
