TYC 2388 Radiator

Overview of TYC Radiator 2388 for Hyundai Elantra and Tiburon

The TYC Radiator 2388 is designed specifically for Hyundai Elantra and Tiburon models, providing reliable engine cooling performance. Constructed with an aluminum core, this radiator supports efficient heat dissipation to maintain optimal engine temperature.

• Core Material: Durable aluminum for effective heat transfer
• Core Dimensions: 25.91 inches height, 14.76 inches length, 0.63 inches thickness
• Flow Configuration: Downflow design for consistent coolant circulation
• Connection Types: Hose clamp inlet and outlet with 1.30-inch diameter
• Fin and Tube Count: 64 fins per 4 inches, 65 tubes total, 66 total fin rows
• Top and Bottom Headers: Both sized 1.97 x 26.58 inches
• Single-row tube design for streamlined cooling

Detailed Features of the TYC Radiator Product Line

The TYC Radiator product line focuses on delivering dependable cooling components tailored to specific vehicle applications. The TYC Radiator 2388 exemplifies this approach by matching exact fitment requirements for Hyundai Elantra and Tiburon models. Its aluminum core and precise flow configuration ensure consistent engine temperature regulation without including transmission or engine oil coolers.

Technical Description and Specifications

This radiator features a downflow core design that promotes efficient coolant movement from the top to the bottom header, both measuring 1.97 by 26.58 inches. The core itself measures 25.91 inches in height, 14.76 inches in length, and 0.63 inches in thickness, providing a balanced surface area for heat exchange. The fin count of 64 every 4 inches and a total of 66 fin rows enhance airflow through the radiator, while the 65 tubes arranged in a single row optimize coolant flow. Hose clamp inlet and outlet connections, each with a 1.30-inch diameter, facilitate secure attachment to the vehicle’s cooling system.

Common Applications and Problem Resolution

• Replacement for leaking or damaged radiators in Hyundai Elantra and Tiburon
• Restores proper engine cooling to prevent overheating
• Addresses reduced cooling efficiency due to clogged or corroded cores
• Eliminates coolant leaks from worn or cracked radiator components
• Supports engine performance by maintaining stable operating temperatures

Installation Notes and Tips

Ensure compatibility with Hyundai Elantra and Tiburon models before installation. Use appropriate hose clamps for inlet and outlet connections sized at 1.30 inches. Inspect surrounding cooling system components for wear or damage during replacement. Properly bleed the cooling system after installation to remove air pockets and verify leak-free connections.

Quality Assurance and Warranty Information

The TYC Radiator 2388 is manufactured to meet OEM specifications for fit and function. Constructed with a corrosion-resistant aluminum core, it is engineered for durability and consistent performance. While specific warranty details are not provided here, TYC products typically come with a limited warranty covering defects in materials and workmanship.
