TYC 2820 Radiator - Front or Primary

Overview of TYC Radiator 2820 for Kia Rio and Rio5

The TYC Radiator 2820 is engineered specifically for Kia Rio and Rio5 models, providing reliable cooling performance. Designed with an aluminum core and integrated transmission oil cooler, this radiator supports efficient engine operation and transmission temperature management.

• Core material: durable aluminum for effective heat dissipation
• Includes concentric transmission oil cooler for integrated cooling
• Downflow design with 1-row tube configuration
• Core dimensions: 25" height, 14.57" length, 0.63" thickness
• Hose clamp inlet and outlet connections with 1.30" and 1.34" diameters
• Fin count of 85 per 4 inches and total 67 fin rows for optimized airflow
• Compatible with Kia Rio and Rio5 vehicles

Detailed Features of the TYC Radiator 2820

This TYC Radiator 2820 features a robust aluminum core that enhances heat transfer efficiency while maintaining lightweight construction. The radiator includes a concentric transmission oil cooler, allowing it to manage transmission fluid temperatures without the need for a separate cooler. Its downflow flow configuration ensures effective coolant circulation through a single row of tubes, measuring 16 by 1.5 inches each. The fin design, with 85 fins every 4 inches and a fin wave height of 0.31 inches, promotes optimal airflow and heat dissipation. Hose clamp inlet and outlet connections with diameters of 1.30 and 1.34 inches respectively provide secure and compatible attachment points for coolant hoses. The top and bottom headers both measure 1.96 by 25.63 inches, supporting structural integrity and fitment.

About the TYC Radiator Product Line

The TYC Radiator product line focuses on delivering reliable cooling solutions tailored to specific vehicle applications. Radiators in this line are designed with quality materials such as aluminum cores and incorporate features like integrated transmission oil coolers when applicable. The TYC Radiator 2820 exemplifies this approach by combining durable construction with precise fitment for Kia Rio and Rio5 models, ensuring compatibility and performance.

Common Applications and Issues Addressed

• Replacement for leaking or damaged radiator cores in Kia Rio and Rio5
• Solves overheating issues caused by inefficient heat dissipation
• Addresses transmission fluid overheating with built-in concentric oil cooler
• Resolves coolant leaks from worn or corroded inlet/outlet connections
• Improves engine cooling system reliability and efficiency

Installation Notes and Tips

When installing the TYC Radiator 2820, ensure all hose clamps are securely fastened to the 1.30" inlet and 1.34" outlet connections to prevent leaks. Verify compatibility with your Kia Rio or Rio5 model year before installation. The downflow design requires proper orientation for optimal coolant flow. Inspect the transmission oil cooler fittings (tube fittings with 0.39" diameter) for secure connection to transmission lines. Professional installation is recommended to maintain system integrity and performance.

Quality Assurance and Warranty

TYC Radiator 2820 is manufactured to meet or exceed OEM specifications for Kia Rio and Rio5 vehicles. The aluminum core and integrated transmission oil cooler are tested for durability and performance under standard operating conditions. While specific warranty details are not provided here, TYC products typically come with a limited warranty covering defects in materials and workmanship. Consult product documentation or supplier for exact warranty terms.
