TYC 2831 Radiator
| Brand | TYC 2831 |
|---|---|
| Bottom Header | 1.97x19.45 |
| Core Height (in) | 18.82 |
| Core Length (in) | 25 |
| Core Material | Aluminum |
| Core Thickness (in) | 0.87 |
| Engine Oil Cooler Included | No |
| Fin Count (every 4") | 68 |
| Fin Wave Height (in) | 0.31 |
| Find Wave Pitch | 3 |
| Flow Configuration | Crossflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter (in) | 1.38 |
| No. Of Rows | 1 |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter (in) | 1.38 |
| Toc Distance (in) | 14.80 |
| Toc Inlet Diameter (in) | 0.31 |
| Toc Inlet Type | Tube fitting |
| Toc Outlet Diameter (in) | 0.31 |
| Toc Outlet Type | Tube fitting |
| Top Header | 1.97x19.45 |
| Total Fin Row Count | 48 |
| Total Tube Count | 47 |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Concentric Oil Cooler |
| Tube Count (every 4") | 10 |
| Tube Width X Height | 22x2 |
| Product line | TYC Radiator |
| Fits | Hyundai · 5 vehicles |
Aluminum core. Lightweight construction helps promote efficient heat transfer.
Crossflow design. Engineered for steady coolant flow through the radiator.
Transmission oil cooler included. Adds integrated cooling in one radiator assembly.
Cross-references APDI 8012831, CSF 2766 and DENSO 221-3704 for the same application. See all 10.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
TYC Radiator for 2008-2010 Hyundai Sonata
The TYC Radiator 2831 is a direct-fit cooling system replacement for 2008-2010 Hyundai Sonata models. Built with an aluminum core and a crossflow design, it includes a concentric transmission oil cooler for vehicles equipped with automatic transmission cooling integration.
Key Features
- Aluminum core construction for efficient heat transfer
- Crossflow radiator layout
- Transmission oil cooler included
- Concentric oil cooler design
- Hose clamp inlet and outlet connections
- Single-row core design
- Fits 2008-2010 Hyundai Sonata, N/A
Product Details
TYC Radiator 2831 is engineered around the listed core dimensions and connection points to match the original cooling layout on the Hyundai Sonata. The radiator uses an aluminum core with a 25-inch core length, 18.82-inch core height, and 0.87-inch core thickness, along with 1.38-inch inlet and outlet diameters. The integrated concentric transmission oil cooler adds fluid cooling support in applications that route transmission oil through the radiator assembly. This part cross-references Spectra Premium CU2831 for the same application.
TYC Radiator is the brand line for TYC cooling components, focused on replacement radiators built to align with OE-style fitment and vehicle-specific dimensions. For this application, the TYC 2831 supports 2008-2010 Hyundai Sonata cooling system service where the original radiator includes transmission oil cooler integration.
Common Problems This Part Can Address
- Coolant leaks from a damaged radiator tank or core
- Overheating caused by restricted or failing radiator flow
- Transmission fluid temperature concerns tied to a worn cooler circuit
- Cracked or corroded radiator connections
- Poor heat dissipation from an aging cooling assembly
Installation Notes
Verify the inlet and outlet sizes, cooler connection style, and core dimensions before installation. Confirm that the vehicle uses the same transmission oil cooler configuration and hose clamp-style radiator connections as the original unit. Flush the cooling system and inspect hoses, clamps, and related seals before installing the replacement radiator.
Quality Assurance
TYC cooling components are built for vehicle-specific replacement use and dimensional consistency. Confirm fitment against the 2008-2010 Hyundai Sonata application and the original radiator configuration before installation.
| Year | Make | Model | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2010 | Hyundai | Sonata | Automatic | 3.3L | V6 | N/A | TYC Radiator |
| 2010 | Hyundai | Sonata | Automatic | 2.4L | L4 | N/A | TYC Radiator |
| 2009 | Hyundai | Sonata | Automatic | 3.3L | V6 | N/A | TYC Radiator |
| 2009 | Hyundai | Sonata | Automatic | 2.4L | L4 | N/A | TYC Radiator |
| 2008 | Hyundai | Sonata | Automatic | 2.4L | L4 | N/A | TYC Radiator |
