TYC 30002 A/C Condenser

Overview of TYC A/C Condenser for Toyota Yaris and Scion iA

The TYC 30002 A/C condenser is designed specifically for select Toyota and Scion models, including the Yaris and Yaris iA. This parallel flow condenser ensures efficient cooling performance and includes a receiver/drier for optimal system operation.

• Parallel flow condenser (PFC) design for improved heat dissipation
• Includes receiver/drier to maintain refrigerant purity
• Core dimensions: 22.09 inches height x 13.70 inches length x 0.47 inches thickness
• Fin height of 5mm for effective airflow and cooling
• Compatible with Scion iA, Toyota Yaris, and Yaris iA models

Detailed Product Description and Specifications

The TYC 30002 A/C condenser features a parallel flow condenser (PFC) configuration, which enhances heat exchange efficiency by allowing refrigerant to flow through multiple parallel channels. This design supports consistent cooling performance in the HVAC system of your Toyota Yaris or Scion iA. The condenser core measures 22.09 inches in height, 13.70 inches in length, and 0.47 inches in thickness, providing a compact yet effective cooling surface. Additionally, the 5mm fin height optimizes airflow through the condenser, contributing to reliable temperature regulation inside the vehicle cabin. The included receiver/drier helps to filter moisture and contaminants from the refrigerant, protecting the A/C system components and extending their service life.

Applications and Common Issues Addressed

• Replacement for damaged or leaking A/C condensers in Toyota Yaris and Scion iA models
• Restores proper refrigerant flow and pressure in the HVAC system
• Resolves reduced cooling efficiency caused by clogged or corroded condensers
• Prevents moisture contamination and refrigerant degradation with the integrated receiver/drier
• Helps eliminate overheating issues related to inefficient heat dissipation

Installation Notes and Tips

When installing the TYC 30002 A/C condenser, ensure the system is properly evacuated and recharged with the correct refrigerant type and amount. Verify that all connections are secure and free of leaks. It is recommended to replace the receiver/drier along with the condenser to maintain system integrity. Proper handling of the condenser fins is important to avoid damage that could reduce cooling performance.

Quality Assurance and Warranty Information

TYC manufactures this A/C condenser to meet or exceed OEM specifications for fit, form, and function. The part number 30002 is backed by TYC's quality standards to ensure durability and reliable operation in Toyota Yaris and Scion iA vehicles. Please refer to TYC's warranty policy for specific coverage details.
