TYC 3656 A/C Condenser

Overview of TYC A/C Condenser 3656 for Ford Edge and Lincoln MKX

The TYC A/C Condenser part number 3656 is designed specifically for Ford Edge and Lincoln MKX models. This parallel flow condenser features a built-in dryer to help maintain optimal air conditioning performance and system reliability.

• Parallel flow configuration for efficient heat exchange
• Built-in dryer to remove moisture and contaminants
• Core dimensions: 16.81 inches height, 27.01 inches length, 0.63 inches thickness
• Inlet diameter of 0.61 inches with block fitting design
• Outlet diameter of 0.40 inches with block fitting design
• Compatible with Ford Edge and Lincoln MKX vehicles

Detailed Product Features and Specifications

The TYC 3656 A/C condenser is engineered with a parallel flow design, which enhances cooling efficiency by allowing refrigerant to flow through multiple parallel channels. This design improves heat dissipation compared to traditional tube-and-fin condensers. The built-in dryer integrated into the condenser helps to remove moisture and contaminants from the refrigerant, protecting the A/C system from corrosion and blockages.

With core dimensions measuring 16.81 inches in height, 27.01 inches in length, and 0.63 inches in thickness, this condenser fits precisely within the HVAC system of compatible vehicles. The inlet and outlet fittings use a block design, with diameters of 0.61 inches and 0.40 inches respectively, ensuring secure and leak-free connections.

Compatible Vehicles and Common Applications

• Replacement condenser for Ford Edge models requiring part number 3656
• Suitable for Lincoln MKX vehicles needing a parallel flow A/C condenser
• Addresses issues such as reduced cooling efficiency and refrigerant leaks
• Helps resolve moisture contamination and system corrosion problems
• Restores proper refrigerant flow and pressure in the A/C system

Installation Notes and Tips

When installing the TYC A/C condenser 3656, ensure the system is fully evacuated and free of contaminants before installation. Verify that the inlet and outlet block fittings match the vehicle’s existing connections to prevent leaks. It is recommended to replace the receiver/dryer or accumulator when installing a new condenser to maintain system integrity. Proper handling and alignment during installation will help avoid damage to the core and fittings.

Quality Assurance and Warranty Information

TYC manufactures this A/C condenser to meet or exceed OEM specifications for fit, form, and function. While specific warranty details are not provided here, TYC products typically come with a limited warranty covering defects in materials and workmanship. Using a TYC condenser ensures compatibility and reliable performance for Ford Edge and Lincoln MKX air conditioning systems.
