TYC 3865 A/C Condenser

Overview of TYC A/C Condenser for Cadillac SRX

The TYC 3865 A/C condenser is designed specifically for Cadillac SRX models, providing reliable cooling performance. Featuring a parallel flow condenser configuration, this part ensures efficient heat exchange to maintain optimal air conditioning function.

• Parallel flow condenser (PFC) design for improved cooling efficiency
• Includes integrated receiver/drier for moisture and debris filtration
• Core dimensions: 19 inches height x 22.5 inches length x 0.63 inches thickness
• Inlet diameter: 7/16 inch; outlet diameter: 5/16 inch for precise fitment
• Compatible with Cadillac SRX models requiring part number 3865

Detailed Product Description

The TYC 3865 A/C condenser is engineered with a parallel flow condenser (PFC) configuration, which enhances refrigerant flow and heat dissipation compared to traditional designs. This condenser includes a receiver/drier component that helps remove moisture and contaminants from the A/C system, protecting internal components and extending system life. The core measures 19 inches in height, 22.5 inches in length, and 5/8 inch (0.63 inches) in thickness, providing a substantial surface area for effective cooling. The inlet and outlet sizes of 7/16 inch and 5/16 inch diameter respectively ensure compatibility with the original equipment specifications of the Cadillac SRX.

Common Applications and Issues Addressed

• Replacement for leaking or damaged A/C condensers in Cadillac SRX vehicles
• Restores proper refrigerant flow and heat exchange efficiency
• Eliminates moisture and debris buildup with integrated receiver/drier
• Resolves reduced cooling performance or A/C system overheating
• Prevents compressor damage caused by contaminated refrigerant

Installation Notes and Tips

When installing the TYC 3865 A/C condenser, ensure the system is fully evacuated and recharged according to manufacturer specifications. Verify inlet and outlet hose connections match the 7/16 inch and 5/16 inch diameters for a secure fit. Inspect the receiver/drier for any signs of contamination before installation. Proper handling and alignment during installation will help maintain system integrity and performance.

Quality Assurance and Warranty

TYC parts are manufactured to meet or exceed OEM standards for fit, form, and function. The 3865 A/C condenser undergoes rigorous quality control to ensure durability and reliable operation in Cadillac SRX vehicles. Warranty coverage details should be confirmed with the distributor or retailer at the time of purchase.
