TYC 623170 Dual Radiator and Condenser Fan Assembly

TYC 623170 Dual Fan Assembly for Volt Cooling

TYC 623170 is a dual radiator and condenser fan assembly built for the cooling system on select Chevrolet Volt models. It includes the shroud and uses PA+GF construction for the shroud and fan blades, with a single male connector and 2 terminals for a direct replacement layout.

Compatible With 2011-2015 Chevrolet Volt cooling system applications, this assembly is specified as a dual fan configuration and is supplied without a wiring harness. The TYC 623170 part number is commonly searched for Chevrolet Volt radiator fan replacement and condenser fan assembly service.

Key Features

• Dual radiator and condenser fan assembly
• Shroud included for a complete assembly-style replacement
• PA+GF shroud material and PA+GF fan blade material
• Single male connector with 2 terminals
• Supplied without wiring harness
• Direct fit application for select Chevrolet Volt models

Detailed Description

This TYC cooling fan assembly is designed for the 2011-2015 Chevrolet Volt and combines radiator and condenser airflow management in one unit. The dual-fan configuration supports cooling performance across the vehicle’s thermal system, while the included shroud helps direct airflow through the core area. If you are replacing a worn Chevrolet Volt fan assembly, TYC 623170 provides the correct configuration for the listed application.

This part cross-references Chevrolet OE numbers 20842242 and 22951192, and Partslink GM3115258 for the same application. Search terms such as Chevrolet Volt dual radiator and condenser fan assembly, 2011-2015 Volt cooling fan replacement, and TYC 623170 fan assembly all point to this exact fitment.

Common Problems This Part Can Address

• Overheating caused by a failed radiator fan assembly
• Weak or inconsistent condenser airflow
• Noise from damaged fan blades or a worn motor assembly
• Cooling system performance issues after fan shroud damage
• Electrical connector-related fan operation faults at the assembly level

Installation Notes and Tips

Verify connector style, terminal count, and the absence of a wiring harness before installation. Confirm the vehicle is a 2011-2015 Chevrolet Volt and match the dual fan, shroud-included configuration to the original unit. Inspect related cooling system components, electrical connections, and mounting points during replacement to ensure proper fit and operation.

Quality Assurance

TYC manufactures replacement cooling components for vehicle-specific applications, and this assembly is built to match the listed fitment and configuration details for the Chevrolet Volt. Use the OE cross-reference numbers and the TYC 623170 part number to confirm application accuracy before purchase.
