Part #: 96110

TYC 96110 HVAC Heater Core - Front

Front
⚙️ 54 vehicles fit this part
🔍
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
$56.70Free Shipping
🚚Free ShippingNo Cost to Continental U.S.
🔄Free Returns*Wrong fit? No cost
🛡️60-Day ReturnsMoney back guarantee
*Free return shipping only qualifies if our fitment verification tool is used.
🔥
✅ In Stock · Ready To Ship Most orders ship same-day if ordered before 1pm CST.
✅OE Direct Replacement — Bolt-on fit, no modifications needed
🚗Fitment: Ford, E-150, E-150 Club Wagon, E-150 Econoline, E-150 Econoline Club Wagon, E-250, E-250 Econoline, E-350 Club Wagon, E-350 Econoline, E-350 Econoline Club Wagon, E-350 Super Duty, and Econoline
🔄Easy Returns — Return within 60 days for a full refund
🚚Fast Shipping — Most orders ship same business day before 1pm CST
Not what you need? Click here for all HVAC Heater Core options

Overview of TYC 96110 HVAC Heater Core

The TYC 96110 HVAC heater core is engineered for reliable heating performance in Ford Econoline vans, including E-150, E-250, and E-350 models. Constructed with durable aluminum, this heater core ensures efficient heat transfer and long-lasting operation.

  • Core material: Aluminum for enhanced heat conduction
  • Core dimensions: 7.56 inches length, 6.78 inches height, 1.57 inches thickness
  • Top and bottom headers sized at 2.03 by 7.05 inches
  • Inlet and outlet connections use hose clamps with diameters of 0.63 and 0.75 inches respectively
  • Compatible with multiple Ford Econoline models including E-150 Club Wagon and E-350 Super Duty

Detailed Product Description

The TYC 96110 heater core is designed to replace the original equipment heater core in Ford Econoline vans such as the E-150, E-150 Club Wagon, E-250, E-350, and their Econoline variants. Its aluminum core material provides efficient heat transfer while resisting corrosion, contributing to a longer service life. The core measures 7.56 inches in length, 6.78 inches in height, and 1.57 inches in thickness, fitting precisely within the HVAC housing. Both the top and bottom headers measure 2.03 by 7.05 inches, ensuring proper alignment and sealing. The inlet and outlet connections are designed for hose clamp fittings, with inlet diameter at 0.63 inches and outlet diameter at 0.75 inches, matching OEM specifications for secure coolant flow.

Common Applications and Issues Addressed

  • Restores heating functionality in Ford E-150 and E-250 Econoline vans
  • Replaces leaking or clogged heater cores causing coolant loss
  • Eliminates insufficient cabin heat due to core blockages
  • Prevents overheating issues related to faulty heater cores
  • Addresses coolant odors inside the vehicle cabin

Installation Notes and Tips

When installing the TYC 96110 heater core, ensure the vehicle is properly drained of coolant to avoid spills. Verify hose clamp sizes match the inlet and outlet diameters of 0.63 and 0.75 inches respectively. Properly align the top and bottom headers (2.03x7.05 inches) to avoid leaks. It is recommended to inspect and replace any worn hoses or clamps during installation to maintain system integrity.

Quality Assurance

TYC manufactures the 96110 heater core to meet or exceed OEM standards for fit and function. The aluminum core material offers corrosion resistance and durability. While specific warranty details are not provided, TYC products typically undergo rigorous quality control to ensure reliable performance in Ford E-150, E-250, and E-350 Econoline vehicles.

BrandTYC
Part Number96110
Core MaterialAluminum
Bottom Header2.03x7.05
Core Height (in)6.78
Core Length (in)7.56
Core Thickness (in)1.57
Inlet Connection TypeHose clamp
Inlet Diameter (in)0.63
Outlet Connection TypeHose clamp
Outlet Diameter (in)0.75
Top Header2.03x7.05

This part fits 54 vehicles. Search below:

YearMakeModelSubmodelBody TypePositionNotes
2004FordE-150BaseStandard Cargo VanFront96110(AC)
2004FordE-150 Club WagonXLTStandard Passenger VanFront96110(AC)
2004FordE-250BaseStandard Cargo VanFront96110(AC)
2004FordE-350 Club WagonXLStandard Passenger VanFront96110(AC)
2004FordE-350 Super DutyBaseExtended Cargo VanFront96110(AC)
2004FordEconolineBaseStandard Cargo VanFront96110(AC)
2003FordE-150BaseStandard Cargo VanN/ASuperseded to 96005
2003FordE-150 Club WagonChateauStandard Passenger VanFront96110(AC)
2003FordE-250BaseExtended Cargo VanFront96110(AC)
2003FordE-350 Club WagonChateauExtended Passenger VanFront96110(AC)
2003FordE-350 Super DutyBaseStripped ChassisFront96110(AC)
2003FordEconolineBaseStandard Cargo VanFront96110(AC)
2002FordE-150XLStandard Passenger VanFront96110(AC)
2002FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
2002FordE-150 Econoline Club WagonXLTStandard Passenger VanFront96110(AC)
2002FordE-250 EconolineBaseExtended Cargo VanFront96110(AC)
2002FordE-350 Club WagonXLStandard Passenger VanFront96110(AC)
2002FordE-350 Econoline Club WagonChateauStandard Passenger VanFront96110(AC)
2002FordE-350 Super DutyBaseCutaway VanFront96110(AC)
2002FordEconolineBaseStandard Cargo VanFront96110(AC)
2001FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
2001FordE-150 Econoline Club WagonChateauStandard Passenger VanFront96110(AC)
2001FordE-250 EconolineBaseExtended Cargo VanFront96110(AC)
2001FordE-350 Econoline Club WagonXLTStandard Passenger VanFront96110(AC)
2001FordE-350 Super DutyBaseExtended Cargo VanFront96110(AC)
2001FordEconolineXLStandard Passenger VanFront96110(AC)
2000FordE-150 EconolineXLStandard Cargo VanN/ASuperseded to 96005
2000FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
2000FordE-150 Econoline Club WagonChateauStandard Passenger VanFront96110(AC)
2000FordE-250 EconolineXLStripped ChassisFront96110(AC)
2000FordE-350 EconolineBaseStandard Cargo VanFront96110(AC)
2000FordE-350 Econoline Club WagonCustomStandard Passenger VanFront96110(AC)
2000FordE-350 Super DutyBaseCutaway VanFront96110(AC)
2000FordEconolineXLStandard Passenger VanFront96110(AC)
1999FordE-150 EconolineXLStandard Cargo VanN/ASuperseded to 96005
1999FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
1999FordE-150 Econoline Club WagonChateauStandard Passenger VanFront96110(AC)
1999FordE-250 EconolineXLStandard Cargo VanFront96110(AC)
1999FordE-350 EconolineBaseStandard Cargo VanFront96110(AC)
1999FordE-350 Econoline Club WagonChateauExtended Passenger VanFront96110(AC)
1999FordE-350 Super DutyXLCutaway VanFront96110(AC)
1999FordEconolineXLStandard Passenger VanFront96110(AC)
1998FordE-150 EconolineXLStandard Cargo VanN/ASuperseded to 96005
1998FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
1998FordE-150 Econoline Club WagonCustomStandard Passenger VanFront96110(AC)
1998FordE-250 EconolineBaseStandard Cargo VanFront96110(AC)
1998FordE-350 EconolineXLCutaway VanFront96110(AC)
1998FordE-350 Econoline Club WagonXLT HDExtended Passenger VanFront96110(AC)
1997FordE-150 EconolineXLStandard Cargo VanN/ASuperseded to 96005
1997FordE-150 EconolineBaseStandard Cargo VanN/ASuperseded to 96005
1997FordE-150 Econoline Club WagonCustomStandard Passenger VanFront96110(AC)
1997FordE-250 EconolineBaseStripped ChassisFront96110(AC)
1997FordE-350 EconolineXLExtended Cargo VanFront96110(AC)
1997FordE-350 Econoline Club WagonXLTStandard Passenger VanFront96110(AC)

* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.

This part directly replaces or is cross-referenced with the following part numbers:

9010028

Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
