TYC 97317 A/C Evaporator Core

Overview of TYC A/C Evaporator Core 97317 for Audi Models

The TYC A/C Evaporator Core 97317 is designed specifically for select Audi vehicles, including the A6, A6 Quattro, R8, and S6. This evaporator core features a parallel flow configuration to optimize cooling efficiency and system performance.

• Parallel flow configuration for efficient refrigerant flow
• Core dimensions: 11.81 inches height, 9.65 inches length, 1.89 inches thickness
• Inlet diameter of 0.61 inches with block-style fitting
• Outlet diameter of 0.72 inches with block-style fitting
• Compatible with Audi A6, A6 Quattro, R8, and S6 models
• TYC part number 97317 ensures precise fit and function

Detailed Product Description and Specifications

The TYC 97317 A/C Evaporator Core is engineered to meet the exact specifications required for Audi A6, A6 Quattro, R8, and S6 vehicles. Its parallel flow design allows refrigerant to pass through multiple channels simultaneously, improving heat exchange efficiency and maintaining consistent cabin cooling. The core measures 11.81 inches in height, 9.65 inches in length, and 1.89 inches in thickness, providing a compact yet effective solution for the HVAC system.

Both the inlet and outlet fittings utilize a block design, with diameters of 0.61 inches and 0.72 inches respectively, ensuring secure connections within the vehicle’s A/C system. This part is manufactured to meet OEM standards, making it a reliable replacement for the original evaporator core in compatible Audi models.

Common Applications and Problem Resolution

This A/C evaporator core is used in the vehicle’s HVAC system to absorb heat from the cabin air, enabling effective air conditioning performance. It is compatible with the following Audi models:

• Audi A6
• Audi A6 Quattro
• Audi R8
• Audi S6

Replacing the evaporator core can address issues such as:

• Reduced cooling efficiency or weak air conditioning output
• Leaks or refrigerant loss within the evaporator core
• Unpleasant odors caused by mold or debris buildup
• Excessive moisture or fogging inside the vehicle cabin
• HVAC system failure related to evaporator core damage

Installation Notes and Tips

Installation of the TYC 97317 evaporator core should be performed by a qualified technician due to the complexity of the HVAC system and refrigerant handling requirements. Proper evacuation and recharging of the A/C system are necessary to ensure optimal performance. Verify all connections, including the block-style inlet and outlet fittings, are secure and leak-free. It is recommended to inspect related components such as the expansion valve and blower motor during replacement.

Quality Assurance and Warranty Information

TYC manufactures the 97317 A/C Evaporator Core to meet or exceed OEM quality standards, ensuring durability and reliable operation. This part undergoes rigorous testing to confirm fitment and performance for the specified Audi models. Warranty coverage details should be confirmed at the point of purchase, as TYC typically offers limited warranties on their HVAC components to protect against defects in materials and workmanship.
