WAI 34004N Starter

Starter for Genesis and Hyundai

This WAI starter, part number 34004N, is built for select Genesis and Hyundai applications with Delco PMGR specifications. It is a new, non-remanufactured unit engineered to deliver the amperage needed for modern electrical demands.

• Permanent magnet gear reduction design for efficient cranking performance.
• 100% new construction, not remanufactured.
• Flange-mount starter with clockwise rotation.
• 11-tooth drive and 1.7 kW power rating.
• Fits 2014-2016 Hyundai Genesis, N/A; 2017 Genesis G80, N/A; 2017 Genesis G90, N/A; 2018 Genesis G80, N/A to 05/23/2018; 2018 Genesis G90, N/A to 05/23/2018.

Detailed Fitment and Function

Use this starter when replacing a worn or failed unit on compatible Genesis and Hyundai models that call for the Delco PMGR configuration. The 34004N is specified with clockwise rotation, flange mounting, and an 11-tooth drive, making it a direct match for applications that require those details. This part cross-references Monroe Shocks & Struts (e.g., 34004, 36100-3F160) for the same application.

Common Issues It Can Address

• No-crank condition when the starter no longer engages.
• Slow or weak engine cranking.
• Intermittent starting caused by internal starter wear.
• Starter noise from a failing drive or gear reduction assembly.
• Electrical starting problems tied to a worn starter motor.

Installation Notes and Quality

Confirm the Delco PMGR specification, 11-tooth drive, clockwise rotation, and flange-mount style before installation. Verify the vehicle build date for 2018 Genesis G80 and G90 applications, since fitment is listed only through 05/23/2018. WAI starters are engineered to provide the amperage output needed for today’s vehicles and are manufactured with proprietary components and processes for long service life and consistent performance.
