Walker 17196 Exhaust Muffler - Right

Walker SoundFX Universal Muffler Overview

Walker SoundFX Universal Muffler 17196 is a universal oval exhaust muffler built for drivers who need a direct-fit style replacement with flexible application coverage. It uses 100% aluminized steel for improved service life versus low-carbon steel and is shaped to deliver a clean appearance with controlled exhaust acoustics.

Compatible With 1990-1996 Pontiac Grand Prix and 1991-1993 Oldsmobile Cutlass Supreme dual-exhaust applications, this Walker muffler is a practical choice when replacing a worn muffler on a Pontiac Grand Prix or Oldsmobile Cutlass Supreme. Part number 17196 is part of the Walker SoundFX Universal line, which focuses on durable construction and balanced sound characteristics.

Key Features

• Universal fit muffler for exhaust system replacement and custom installation
• Oval body shape with a regular grade construction
• 100% aluminized steel body for longer service life than low-carbon steel
• Mechanical interior joints and spun-locked heads for added durability
• Center inlet and offset outlet pipe connection layout
• 1.75-inch inlet and 1.75-inch outlet inside diameter
• Walker SoundFX Universal part number 17196

Detailed Description

Walker SoundFX Universal Muffler 17196 is designed for exhaust system service where a universal muffler is needed with a compact oval profile. The 14-inch body length, 9.75-inch body width, and 4.25-inch body height provide a low-profile package, while the aluminized steel finish helps resist corrosion in everyday driving conditions. The center inlet and offset outlet configuration supports a range of exhaust routing needs, especially on dual-exhaust Pontiac Grand Prix and Oldsmobile Cutlass Supreme applications.

This muffler is part of the Walker SoundFX Universal product line, which emphasizes durable construction and controlled exhaust tone without relying on tunability or reversible orientation. If you are searching for Walker 17196 for a Pontiac Grand Prix muffler replacement or an Oldsmobile Cutlass Supreme exhaust muffler, this unit provides a straightforward universal solution with the specified 1.75-inch pipe connection size.

Common Problems It Can Address

• Rust-through or corrosion in an existing muffler
• Excessive exhaust noise from a damaged muffler shell
• Poor exhaust flow caused by internal muffler deterioration
• Need for a replacement muffler with a center-inlet, offset-outlet layout
• Service replacement on dual-exhaust Pontiac Grand Prix or Oldsmobile Cutlass Supreme systems

Installation Notes and Tips

• Compatible With 1990-1996 Pontiac Grand Prix, right and N/A positions, with dual exhaust; modifications and/or additional parts may be required for installation.
• Compatible With 1991-1993 Oldsmobile Cutlass Supreme, right and N/A positions, with dual exhaust; modifications and/or additional parts may be required for installation.
• Verify inlet and outlet diameter, body dimensions, and routing before welding or clamping into place.
• Because this is a universal muffler, confirm clearance around the oval body and offset outlet during mock-up.
• Check the existing exhaust layout for the correct center-inlet and offset-outlet orientation before final installation.

Quality Assurance

Walker builds SoundFX Universal mufflers with aluminized steel, mechanical interior joints, and spun-locked heads to support durability and consistent fitment characteristics. Part number 17196 is engineered for service replacement use in the listed Pontiac Grand Prix and Oldsmobile Cutlass Supreme applications.
