Walker 225-1015 Manifold Absolute Pressure Sensor

Overview of Walker Products Manifold Absolute Pressure Sensor

The Walker Products 225-1015 Manifold Absolute Pressure (MAP) Sensor is designed for precise engine management in select Dodge and Jeep vehicles. This sensor plays a critical role in monitoring engine load by measuring the manifold pressure, ensuring optimal fuel delivery and engine performance.

• Terminal Type: Pin
• Connector Shape: Rectangular
• Terminal Quantity: 3
• Connector Gender: Female
• Terminal Gender: Male

Detailed Product Description

The Walker Products 225-1015 MAP Sensor features a three-pin design with a rectangular female connector, providing secure and reliable electrical connections. The pin terminal type and male terminal gender ensure compatibility with the vehicle’s wiring harness. This sensor is engineered to deliver accurate manifold pressure readings, which are essential for the engine control unit (ECU) to adjust fuel injection and ignition timing effectively.

Walker Products is known for its focus on emission control components, and this MAP sensor is part of their emission control sensors line. The 225-1015 sensor is manufactured to meet or exceed OEM specifications, making it suitable for use in various Dodge and Jeep models.

Compatible Vehicles

This MAP sensor is compatible with a range of Dodge and Jeep vehicles, including:

• Dodge B150, B250, B350, B1500, B2500, B3500
• Dodge D150, D250, D350
• Dodge Dakota
• Dodge Ram 1500, Ram 2500, Ram 3500
• Dodge Ramcharger
• Dodge W150, W250, W350
• Jeep Grand Cherokee
• Jeep Viper

Common Issues Addressed by the MAP Sensor

• Erratic engine idling or stalling
• Poor fuel economy due to incorrect air-fuel mixture
• Check Engine Light triggered by faulty manifold pressure readings
• Reduced engine power and acceleration
• Increased emissions and failed emissions tests

Installation Notes and Tips

• Ensure the connector is fully seated with the rectangular female connector to avoid loose connections
• Verify the three-pin terminal alignment before installation
• Disconnect the battery before replacing the sensor to prevent electrical shorts
• Inspect the wiring harness for damage or corrosion prior to installation
• Use OEM torque specifications when securing the sensor to avoid damage

Quality Assurance and Warranty

The Walker Products 225-1015 MAP Sensor is manufactured under strict quality control standards to ensure durability and reliable performance. Walker Products emission control sensors are designed to meet or exceed original equipment manufacturer requirements. Warranty coverage details should be confirmed with the product supplier or manufacturer documentation.
