Walker 256-1092 Engine Oil Pressure Switch

Engine Oil Pressure Switch for OE-Style Monitoring

Walker 256-1092 is an OE replacement engine oil pressure switch built to monitor lubrication pressure and send the correct signal to the ECU or dashboard warning circuit. It is designed for Volkswagen Golf, Volkswagen Jetta, Volkswagen Passat, Audi A3 Sportback e-tron, and Audi A8 Quattro applications that require the specified pressure threshold and connector style.

• OE replacement oil pressure switch for engine lubrication monitoring
• Matches OE pressure thresholds, thread size, terminal type, and electrical response
• Metal and plastic construction with oil-resistant, high-temperature materials
• 1 female connector, 1 male blade-pin terminal
• Green connector style for listed applications
• Direct-fit replacement for factory mounting locations such as the engine block or oil filter housing

Fitment Details

Fits 2019-2021 Volkswagen Golf, N/A. Fits 2019-2021 Volkswagen Jetta, N/A. Fits 2019 Volkswagen Golf SportWagen, N/A, 2 Pin (Green). Fits 2016-2018 Audi A3 Sportback e-tron, N/A, 0.30-0.60 BAR. Fits 2013-2018 Volkswagen Jetta, N/A, 0.30-0.60 BAR. Fits 1999-2004 Volkswagen Jetta, N/A, 0.30-0.60 BAR. Fits 2012-2014 Volkswagen Passat, N/A. Fits 2011-2012 Audi A8 Quattro, N/A. Fits 1998-2003 Volkswagen Beetle, N/A, 0.30-0.60 BAR. Fits 2001 Volkswagen Golf, N/A, 0.30-0.60 BAR.

What It Helps Address

• Oil warning light flickering or staying on
• False low-oil-pressure alerts
• No warning signal when oil pressure drops below safe limits
• Faulty ECU input from a worn pressure switch
• Intermittent oil pressure warning behavior after engine service or repair

Installation Notes

Install the switch in the factory oil pressure switch location and connect it to the existing wiring harness without modification. Verify the connector style, terminal count, and pressure specification before installation, especially on Volkswagen Jetta, Volkswagen Golf, and Audi A3 Sportback e-tron applications. The part number 256-1092 should be matched to the vehicle’s OE-style pressure range and connector configuration before replacement.

Quality Assurance

Walker Products manufactures this oil pressure switch to OE replacement standards for fit, electrical response, and pressure calibration. Part number 256-1092 is built for consistent operation in engine environments where heat and oil exposure are constant. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.
