Walker 256-1206 Engine Oil Pressure Switch
| Brand | Walker 256-1206 |
|---|---|
| Material | Metal |
| Material | Plastic |
| Length | 54.00 |
| Color | Blue |
| Terminal Type | Blade pin |
| Connector Quantity | 1 |
| Terminal Quantity | 1 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Fits | Audi · 13 vehicles |
OE replacement. Matches factory pressure thresholds, thread size, and electrical response.
Metal and plastic construction. Built for consistent performance under heat and oil exposure.
Blade-pin connection. Uses a female connector with one terminal for straightforward wiring.
Engine Oil Pressure Switch for Audi Applications
Walker 256-1206 is an OE replacement engine oil pressure switch built to monitor lubrication pressure and send the correct signal to the ECU or dash warning circuit. It is a direct-fit solution for select Audi models, including Audi Q7, Audi A6 Quattro, Audi A7 Quattro, and Audi A8 Quattro applications.
- OE replacement oil pressure switch for factory-style monitoring
- Matches OE pressure threshold, thread size, terminal type, and electrical response
- Metal and plastic construction with oil-resistant, high-temperature materials
- Blade pin terminal design with 1 female connector and 1 male terminal
- Direct-fit installation at the engine block or oil filter housing location
- Walker 256-1206 for select 2015-2019 Audi vehicles
Detailed Product Overview
This Walker oil pressure switch is engineered to restore accurate pressure signaling in the engine lubrication system. It is built for select 2015-2019 Audi models and is designed to thread into the factory mounting point without modification. For drivers searching for an Audi Q7 oil pressure switch, an Audi A6 Quattro oil pressure switch, or Walker 256-1206 for Audi A8 Quattro and A7 Quattro applications, this part provides the OE-style electrical response needed for proper warning-light or ECU input operation.
Walker Products manufactures this switch to align with original equipment specifications, including the correct terminal style and connector configuration. The result is a replacement that integrates with existing wiring and supports consistent oil pressure monitoring under normal engine heat and oil exposure.
What It Helps Address
- Oil warning light flickering or intermittent illumination
- False low-oil-pressure warnings
- No signal to the dash or ECU when pressure drops
- Faulty oil pressure switch diagnosis during drivability repair
- Oil pressure monitoring issues during engine service or rebuild work
Installation Notes and Tips
Install the switch in the original factory location, typically on the engine block or oil filter housing, and connect it to the existing harness using the OE-style blade pin terminal interface. Verify thread engagement, connector fit, and system operation after installation. This part cross-references Bosch (e.g., 0281002907) for the same application.
Quality Assurance
Walker 256-1206 is manufactured as an OE replacement component with materials selected for prolonged exposure to engine heat and oil. It is built to meet the functional requirements of the original pressure-switch application on compatible Audi vehicles.
| Year | Make | Model | Liters | Cylinders | Notes |
|---|---|---|---|---|---|
| 2019 | Audi | Q7 | 3.0L | V6 | — |
| 2018 | Audi | A6 Quattro | 3.0L | V6 | — |
| 2018 | Audi | A7 Quattro | 3.0L | V6 | — |
| 2018 | Audi | A8 Quattro | 3.0L | V6 | — |
| 2018 | Audi | Q7 | 3.0L | V6 | — |
| 2017 | Audi | A6 Quattro | 3.0L | V6 | — |
| 2017 | Audi | A7 Quattro | 3.0L | V6 | — |
| 2017 | Audi | A8 Quattro | 3.0L | V6 | — |
| 2017 | Audi | Q7 | 3.0L | V6 | — |
| 2016 | Audi | A6 Quattro | 3.0L | V6 | — |
| 2016 | Audi | A7 Quattro | 3.0L | V6 | — |
| 2016 | Audi | A8 Quattro | 3.0L | V6 | — |
| 2015 | Audi | A8 Quattro | 3.0L | V6 | — |
