Walker 270-1118 Engine Coolant Temperature Sensor Connector

Engine Coolant Temperature Sensor Connector

Walker 270-1118 is an OE-style engine coolant temperature sensor connector built for direct repair of damaged or heat-affected wiring at the sensor interface. It uses a molded connector housing with pre-terminated leads and the correct spade terminal layout for a factory-style electrical connection.

Compatible with select Ford, Mercury, and Mazda applications, including Ford Fusion, Ford Escape, Ford Focus, Ford Ranger, Mercury Milan, Mercury Mariner, Mazda Tribute, and Mazda Tribute engine coolant temperature sensor connector repairs.

Key Features

• OE replacement engine coolant temperature sensor connector
• Molded OE-style connector housing for factory-style fit
• Pre-terminated leads for repair work at the harness side
• High-quality copper wire and insulation for electrical continuity
• Built to resist heat, oil, and chemical exposure in engine-bay environments
• 2-terminal spade design with male connector and female terminals
• Walker 270-1118 cross-references Standard Ignition S-816 and 1P1304

Detailed Description

Walker 270-1118 is designed to restore a reliable connection at the engine coolant temperature sensor when the original connector is cracked, corroded, or no longer locking securely. The OE-style housing and pre-terminated leads help match the factory sensor connection without modifying the mating component. This makes it a practical repair part for drivability diagnostics and electrical service on vehicles such as Ford Fusion, Ford Escape, and Ford Focus.

The connector is built with copper conductors and insulation selected for current capacity, flexibility, and resistance to underhood heat and contamination. Walker 270-1118 supports clean sensor signal transfer in areas where wiring commonly degrades, including the engine bay and other high-temperature locations. For technicians searching for a Ford Ranger coolant temperature sensor connector or a Mercury Milan engine coolant temperature sensor connector, this part provides an OE-style repair solution.

What It Helps Repair

• Broken or brittle coolant temperature sensor connector housings
• Corrosion at the sensor plug or terminal interface
• Intermittent temperature signal loss
• Hard starting, poor idle, or drivability issues tied to sensor wiring faults
• Check engine light concerns related to coolant temperature circuit problems

Installation Notes and Tips

Install using standard crimp or solder repair methods and verify wire routing before final assembly. Match the connector orientation to the original sensor plug and inspect the harness for heat damage or corrosion before splicing. This part fits 2006-2009 Ford Fusion, 2006-2009 Mercury Milan, 2004-2008 Ford Escape, 2008 Mazda Tribute, 2005-2006 Mazda Tribute, 2005-2008 Mercury Mariner, 2005-2007 Ford Focus, 2003 Ford Focus, 2005 Ford Ranger, 2001-2003 Ford Ranger, and 2004 Ford Focus from 04/05/04.

Quality Assurance

Walker Products designs these electrical pigtails as OE replacement components with factory-style housings and materials selected for dependable long-term electrical repair. Part number 270-1118 is engineered for direct connector replacement in the listed applications.
