Wix 51521 Engine Oil Filter

Reliable Engine Oil Filtration for Nissan and Volkswagen Vehicles

The Wix 51521 engine oil filter is designed to provide dependable oil filtration for select Nissan and Volkswagen models, including the 200SX, 280ZX, Maxima, Pathfinder, and Vanagon. This spin-on lube filter ensures consistent engine protection by maintaining optimal oil flow and filtration efficiency.

Key Features of the Wix 51521 Engine Oil Filter

• Anti-Drain Back Valve to prevent dry starts and maintain oil pressure
• Enhanced cellulose media material for effective contaminant capture
• Beta Ratio of 2/20=6/20 for reliable filtration performance
• Burst pressure rating of 325 psi for durability under high stress
• Bypass relief valve setting between 8-11 psi to ensure continuous oil flow
• Spin-on style with 3/4-16 thread size for easy installation
• Flow rate between 7-9 gallons per minute to support engine demands
• Compact dimensions: 3.780 inches height and 3.661 inches outer diameter

Detailed Description and Technical Specifications

The Wix 51521 engine oil filter is engineered with enhanced cellulose media that effectively traps contaminants down to 21 microns, helping to protect engine components from wear. Its anti-drain back valve prevents oil from draining out of the filter when the engine is off, reducing dry starts and extending engine life. The filter’s bypass relief valve activates between 8 and 11 psi, allowing oil to bypass the filter element if it becomes clogged, ensuring continuous lubrication. Rated with a burst pressure of 325 psi, this filter withstands high-pressure conditions common in heavy-duty applications. The spin-on design with a 3/4-16 thread size simplifies replacement on compatible Nissan and Volkswagen vehicles.

Compatible Vehicles and Applications

• Nissan 200SX, 280ZX, 510, 720, 810, D21, Maxima, Pathfinder, Pickup
• Volkswagen Vanagon

Common Issues Addressed by the Wix 51521 Oil Filter

• Prevents engine wear caused by contaminants in the oil
• Reduces risk of oil starvation during engine startup with anti-drain back valve
• Maintains proper oil flow even if the filter element becomes clogged
• Protects engine components from damage due to oil pressure fluctuations
• Helps extend engine life by ensuring clean oil circulation

Installation Notes and Tips

• Ensure the engine is cool before removing the old oil filter
• Apply a thin layer of clean engine oil to the gasket of the new filter for a proper seal
• Hand-tighten the Wix 51521 filter until the gasket contacts the mounting surface, then tighten an additional 3/4 turn
• Check for leaks after installation and during initial engine operation
• Dispose of the used oil filter according to local regulations

Quality Assurance and Warranty Information

Wix filters are manufactured to meet industry standards for filtration efficiency and durability. The 51521 model is classified as Class A and designed for light-duty applications, ensuring reliable performance in compatible Nissan and Volkswagen vehicles. While specific warranty details may vary, Wix typically offers coverage against defects in materials and workmanship. For precise warranty terms, consult the product documentation or Wix customer support.
