Wix WF10059 Fuel Water Separator Filter

Overview of Wix WF10059 Fuel Water Separator Filter

The Wix WF10059 fuel water separator filter is engineered to provide reliable fuel filtration and water separation for heavy-duty diesel engines. Designed with a spin-on style and cellulose media, this filter helps maintain fuel system integrity and engine performance in demanding conditions.

• Beta Ratio: 2/75=3/9 for efficient contaminant removal
• Burst Pressure: 200 psi ensuring durability under pressure
• Collapsed Pressure Rating: 100 psi for reliable operation
• Drain Cock: Equipped with a drain cock for easy water removal
• Filter Area: 913 square inches for extended filtration capacity
• Micron Rating: 3.00 microns for fine particle filtration
• Height: 8.125 inches, Outer Diameter Top: 4.280 inches
• Thread Size: 1-14, spin-on fuel/water separator style
• Media Material: Cellulose for effective filtration

Technical Details and Performance

The WF10059 filter is classified as heavy-duty (Hd) for both class and duty type, making it suitable for rigorous fuel system applications. Its cellulose media captures contaminants down to 3 microns, while the beta ratio of 2/75=3/9 indicates a high level of filtration efficiency. The filter’s burst pressure rating of 200 psi and collapsed pressure rating of 100 psi ensure it withstands the stresses of heavy-duty fuel systems without failure. The integrated drain cock allows for convenient water drainage, preventing water accumulation that can damage fuel injectors and engine components.

Compatible Vehicles and Applications

This Wix WF10059 fuel water separator filter is compatible with a range of heavy-duty diesel engines commonly found in trucks and commercial vehicles. It is designed to fit applications requiring a 1-14 thread size and spin-on filter style. For example, it is suitable for use in diesel-powered Ford F-Series trucks, Chevrolet Silverado HD models, and Ram 2500/3500 vehicles that specify this part number or equivalent fuel water separator filters.

Common Issues Addressed by WF10059 Filter

• Prevents water contamination in diesel fuel systems
• Reduces fuel injector clogging and wear
• Protects engine components from corrosion caused by water
• Maintains fuel system pressure and flow consistency
• Extends fuel filter service intervals with large filter area

Installation Notes and Tips

When installing the Wix WF10059, ensure the old filter is fully drained and the mounting surface is clean. Hand-tighten the spin-on filter until the gasket contacts the base, then tighten according to manufacturer torque specifications. Use the drain cock to remove accumulated water regularly to maintain optimal filter performance. Always verify compatibility with your vehicle’s make and model before installation.

Quality Assurance and Warranty

Wix filters are manufactured to meet industry standards for heavy-duty fuel filtration. The WF10059 undergoes rigorous testing for burst and collapsed pressure ratings to ensure durability and reliability. While specific warranty details are not provided here, Wix typically offers warranties covering defects in materials and workmanship. Consult Wix or your parts supplier for exact warranty terms related to this filter.
