Wix WF8059 Fuel Filter

Brand Wix WF8059
BetaRatio 2/20/75=4/8/13
Class C
Duty Type Ld
Height 4.803
Inner Diameter Top Closed
Micron 4.00
Outer Diameter Top 3.26
Style Spin-on fuel/water separator f
Thread Size 20x1.5 mm
Fits —

Fuel/water separation. Helps keep contamination out of the fuel system.

Spin-on design. Makes service quick and straightforward.

4-micron filtration. Captures very fine particles for cleaner fuel flow.

Cross-references ACDelco XD 159, ACDelco XD 9024 E and ACDelco XD 9287 E for the same application. See all 118.

$30.43Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing β€” free returns if it doesn't
Step 2 — Quantity
Order total $30.43
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Wix WF8059 Fuel Filter Overview

The Wix WF8059 is a spin-on fuel/water separator built for light-duty diesel fuel systems that need clean, dry fuel delivery. With a 4 micron rating and a closed-top design, it supports filtration performance where water separation and fine contaminant control matter.

Compatible With applications that use a 20 x 1.5 mm thread and a spin-on fuel/water separator format, including select Isuzu, Mitsubishi, Mazda, Kia, Yanmar, and General Motors vehicles and equipment. The WF8059 is also cross-referenced to NAPA Gold Filters 308059 for the same application.

Key Features

  • Part number: WF8059
  • Spin-on fuel/water separator style
  • 4 micron filtration rating
  • 20 x 1.5 mm thread size
  • Closed inner diameter top
  • 4.803 in. height
  • Outer diameter top: 3.26 in.
  • Beta ratio: 2/20/75 = 4/8/13
  • Class C, light-duty duty type

Detailed Description

Wix WF8059 is engineered as a fuel filter for systems that require separation of fuel and water along with fine particulate filtration. The 4 micron media specification and beta ratio data indicate a filter built to capture small contaminants before they reach sensitive fuel-system components. Its spin-on format and 20 x 1.5 mm thread size make it a direct-service style filter for supported applications.

This part number WF8059 is commonly associated with select diesel applications across Isuzu, Mitsubishi, Mazda, Kia, and Yanmar platforms, as well as other equipment using the same mounting and thread specifications. For buyers searching by vehicle, Wix WF8059 is a relevant replacement fuel filter for select Isuzu and Mitsubishi diesel applications where a spin-on fuel/water separator is specified.

What It Helps Address

  • Water contamination in diesel fuel
  • Fine sediment and particulate buildup in the fuel system
  • Restricted fuel flow caused by a loaded filter
  • Injector and pump wear linked to dirty fuel
  • Service intervals that require a replacement spin-on separator

Installation Notes

Verify thread size, sealing surface, and filter height before installation. Confirm the vehicle or equipment calls for a spin-on fuel/water separator with a 20 x 1.5 mm thread and the same physical dimensions as the WF8059. Prime and bleed the fuel system according to the service procedure after replacement, especially on diesel applications.

For fitment-based searches, this filter is used in select Isuzu diesel applications, select Mitsubishi diesel applications, and other compatible fuel systems that specify the same filter format. Always match the OE part number or service specification before installation.

Quality Assurance

Wix positions filtration as a core part of maintenance, and this filter follows that approach with defined micron and beta ratio specifications for service consistency. The WF8059 is built to support dependable fuel-system filtration in the applications that call for it.

This part fits 0 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelPositionNotes
Directly replaces or cross-references 118 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
ACDelco — XD 159ACDelco — XD 9024 EACDelco — XD 9287 EAL Filter — ALG-2061ASAS — SPFC 326Baldwin — BF7838BluePrint Engines — ADC 42305BluePrint Engines — ADG02319Bosch — 0 986 450 722Bosch — 1 457 434 435Bosch — N4435Briggs & Stratton — 820 311Brunswick Mercruiser — 882376CARQUEST Premium Filters — 96649CARQUEST Premium Filters — Z 951Champion — CFF100148Champion — L 148Champion — L 148/606clean filters — DN 898COMLINE Auto Parts — CKI13002Coopers — FSM 4103Coopers — Z 951Crosland — 5020Daihatsu — 23303-87701Daihatsu — 2330387781Delphi — FF0062Donaldson — P502142Filtron — PP 853Fleetguard — FF5229FRAM — LF30K1FRAM — P5173General Motors — 94419532Goodwill — FG 504Hitachi Construction Machinery — 4294844Hoffer Products — 7690119IPS — IFG-3K03Isuzu — 8-94151-010-0Isuzu — 8-94151-010-1Isuzu — 8-94419-532-0Isuzu — 9-44195-32Jakoparts — J1330311Jakoparts — J1335009Jakoparts — J1336007Japan Parts — 30-05-509Japan Parts — 30-K0-003Japan Parts — FC-509Japan Parts — FC-509SJapan Parts — FC-K03SJapan Parts — JFC-509Japan Parts — JFC-509SKawasaki — 510561051Kia — 0 K65B 23 570 AKia — 0 K71E 23 570 AKia — 0 K551 23 570Kia — 0 K551 23 570 AKia — 0K71E23570Kia — MB433425Kolbenschmidt — 50 013 804Kolbenschmidt — 804-FSKomatsu — Z148944195320LUBER-FINER — LFF5950M Filter — MP 470Magneti Marelli — 71760793Magneti Marelli — FD 524Mann-Filter — WK 815 XMazda — PN12-13-ZA5Meat & Doria — 4119Meat & Doria — 4309MEYLE — 42-14 323 0001Mitsubishi — MB 433425Mitsubishi — RN 1213ZA5Mitsubishi — XB 433425Motaquip — VFF 168Mueller — FN102Nanni Diesel — 48100780BNAPA Gold Filters — 308059Nipparts — J1335009Nipparts — J1336007Opel — 4295415PBR — BG-1537PBR — BG-1559Purflux — CS440Purolator — F 57585Ryco — Z539Sakura — FC1006Savara — SN 543Schupp — SK 3672Schupp — SK 3777Sofima — S 4339 NRTCM — 2080102131TCM — 2080102132Tecnocar — RN202Teho — 6052Teho — OK 52Toro — 1003192TRP — 1500554UFI — 24.339.00UFI — 24.368.00Union Japan — FC-328Unipart Automotive — GFE 5317VIC — FC-326VIC — FC-509VIC — FC-713Wix Europe — WF8059Woodgate — WGF9223Yanmar — 129574-55710Yanmar — 129574-55711YUILFILTER — YFMI-002DF-7854ELG5255FS 158HDF 525KC 82KC 82DKC 132MF-4551YF-9103Z 273
