Wix WL7506 Engine Oil Filter

Overview of Wix WL7506 Engine Oil Filter

The Wix WL7506 engine oil filter is designed for reliable oil filtration in select Mercedes-Benz and Smart vehicles. Engineered with cellulose media and a cartridge lube metal-free style, this filter supports efficient engine performance and protection.

• Class D filtration for standard duty applications
• Cellulose media material for effective contaminant capture
• Cartridge lube metal-free filter style
• Height of 2.5 inches with precise diameter specifications
• Compatible with Mercedes-Benz CLA200, GLA200, and Smart Fortwo models

Technical Specifications and Design Features

The WL7506 oil filter features a 2.5-inch height and an outer diameter of 3.54 inches at both top and bottom, ensuring a secure fit in compatible vehicles. The inner diameter at the bottom measures 0.71 inches, while the top is closed, consistent with cartridge-style filters. The cellulose media material provides a balance of filtration efficiency and flow rate suitable for light-duty engine applications. The metal-free cartridge design reduces the risk of corrosion and simplifies disposal.

Compatible Vehicles and Applications

This Wix WL7506 oil filter is compatible with specific Mercedes-Benz and Smart models, including the Mercedes-Benz CLA200 and GLA200, as well as the Smart Fortwo. It is intended for use in engines requiring a Class D, light-duty oil filter that meets OEM specifications for these vehicles.

• Helps maintain engine oil cleanliness in Mercedes-Benz CLA200 and GLA200
• Supports oil filtration needs for Smart Fortwo engines
• Prevents premature engine wear caused by contaminants
• Reduces risk of oil flow restriction due to clogging
• Assists in maintaining optimal engine performance and longevity

Installation Notes and Tips

When installing the Wix WL7506 oil filter, ensure the engine is cool and the vehicle is securely lifted if necessary. Remove the old filter cartridge carefully to avoid spillage. Lubricate the new filter’s sealing surface with clean engine oil before installation to ensure a proper seal. Tighten the filter according to manufacturer torque specifications to prevent leaks. Dispose of the used filter in accordance with local regulations.

Quality Assurance and Warranty Information

Wix filters are manufactured to meet industry standards for filtration and durability. The WL7506 model undergoes rigorous quality control to ensure consistent performance. While specific warranty details may vary, Wix typically offers coverage against defects in materials and workmanship. Consult product documentation or authorized sources for exact warranty terms.
