Zimmermann 150.3428.54 Disc Brake Rotor - Front
| Brand | Zimmermann 150.3428.54 |
|---|---|
| Position | Front |
| Bolt Hole Circle Ø 1 [mm] | 120 |
| Brake Disc Type | Internally vented |
| Centering Diameter [mm] | 79 |
| Height [mm] | 73 |
| Hole Arrangement / Number | 6/5 |
| Inspection Tag | Ece r90 approved |
| Machining | High-carbon |
| Minimum thickness [mm] | 22,4 |
| Outer Diameter | 330 |
| Paired article numbers | 150.3428.55 |
| Surface | Coated |
| Thickness [mm] | 24 |
| Weight [kg] | 9,1 |
| Fits | BMW · 5 vehicles |
OE-style replacement. Built as a direct-fit brake rotor for specified BMW brake service.
Coated surface. Helps protect exposed metal and supports cleaner handling before installation.
ECE R90 approved. Meets the recognized replacement brake standard for regulated service.
Cross-references BBB Industries 17661, Brembo 09.A259.1X and Brembo 09.A259.11 for the same application. See all 41.
Overview
Zimmermann 150.3428.54 is an internally vented disc brake rotor with a coated surface and high-carbon machining. It is built for direct brake service on select BMW applications and carries ECE R90 approval for regulated replacement use.
This rotor fits 2012 BMW X1, front; 2004-2006 BMW 330i, front; and 2006 BMW 330xi, front. The 330 mm outer diameter, 24 mm thickness, and 22.4 mm minimum thickness support the specified brake setup.
Key Features
- Internally vented disc brake rotor for heat management during braking.
- High-carbon machining for stable rotor construction.
- Coated surface for added corrosion resistance on exposed metal surfaces.
- ECE R90 approved for compliant replacement service.
- 330 mm outer diameter with 6/5 hole arrangement and 120 mm bolt circle.
Detailed Description
Zimmermann 150.3428.54 is a front disc brake rotor engineered around the listed dimensions and mounting pattern for BMW brake systems. The internally vented design helps move air through the rotor body, while the coated finish protects the surface before and after installation. With a 79 mm centering diameter and 73 mm height, this rotor is specified for the applications shown and should be matched to the vehicle’s brake requirements before installation. This part cross-references Brembo (e.g., 09.A259.1X, 09.A259.11) for the same application.
Use this rotor when replacing worn, warped, or below-spec brake discs on BMW X1, BMW 330i, and BMW 330xi front brake systems. The part number 150.3428.54 is also referenced in interchange listings for related replacement sourcing, and 150.3428.54 should be verified against the existing rotor dimensions before purchase.
Common Uses
- Correcting brake pulsation caused by rotor wear or thickness variation.
- Replacing a rotor that has reached minimum thickness.
- Restoring braking performance after scoring or heat checking.
- Addressing corrosion on the rotor surface.
Installation Notes
Confirm rotor diameter, thickness, centering diameter, bolt circle, and hole arrangement against the vehicle’s brake specification before installation. Clean the hub mounting surface and inspect pads, calipers, and hardware condition during service. After installation, follow the vehicle manufacturer’s bedding procedure for new brake rotors.
Quality Assurance
Zimmermann rotor 150.3428.54 is ECE R90 approved, indicating compliance with the applicable replacement brake standard for the listed applications.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2012 | BMW | X1 | 2.0L | L4 | Front | — |
| 2006 | BMW | 330i | 3.0L | L6 | Front | — |
| 2006 | BMW | 330xi | 3.0L | L6 | Front | — |
| 2005 | BMW | 330i | 3.0L | L6 | Front | — |
| 2004 | BMW | 330i | 3.0L | L6 | Front | — |
