Sealed Power WH497P Engine Piston

Sealed Power WH497P Engine Piston

Sealed Power WH497P is a standard-size hypereutectic engine piston built for specific Ford, Mercury, and Mazda applications. It features a flat head design with a 9.2:1 compression ratio, making it a direct-fit choice for rebuilds that need accurate bore, pin, and compression specifications.

Key Features

• Part number WH497P from Sealed Power
• Standard-size piston with 3.5039 in. bore / 89.0000 mm bore
• Hypereutectic material for modern engine rebuild requirements
• Flat head design with 9.2:1 compression ratio
• 1.515 in. compression distance
• 0.9122 in. pin diameter with 0.06 in. pin offset
• Ring groove widths: 1.50 mm, 1.50 mm, and 4.00 mm
• Minimum clearance: 0.0015 at 1.600 from top of head

Detailed Description

WH497P is engineered as a standard replacement piston for engine block service where bore size, compression height, and ring groove dimensions must match the original build specification. The hypereutectic construction supports consistent performance in modern engines, while the flat head profile and 9.2:1 compression ratio align with the listed Ford Ranger, Ford Taurus, Ford Aerostar, Ford Windstar, Ford Probe, Mercury Sable, Mercury Topaz, and Mazda B3000 applications. Sealed Power uses advanced materials and ISO/QS-certified manufacturing practices to produce parts that meet demanding engine rebuild standards. This part cross-references Hepu P1575 for the same application.

What This Piston Helps Address

• Worn or damaged piston surfaces during engine overhaul
• Compression loss caused by piston wear or mismatch
• Incorrect bore or compression height during rebuild work
• Ring seal issues tied to out-of-spec piston dimensions
• Restoration work on Ford Ranger, Ford Taurus, and Mazda B3000 engines

Installation Notes and Tips

Verify bore size, compression distance, pin diameter, and ring groove widths before assembly. WH497P is a standard-size piston, so cylinder measurements should be checked carefully during machine work. Confirm the correct ring set for the application, including the noted WE-446K or WE-446X ring set where specified for certain fitments. Follow factory service procedures for clearance checks, ring end gap, and piston orientation during installation.

Quality Assurance

Sealed Power manufactures this piston using leading-edge materials and certified production processes to support consistent rebuild quality. The WH497P part number is backed by Sealed Power’s engine component engineering standards for precision fit and repeatable performance.

Compatible With

• Fits 1999-2001 Mercury Sable, N/A
• Fits 1999-2000 Ford Windstar, N/A
• Fits 1994-1999 Mazda B3000, N/A
• Fits 1991-1998 Ford Ranger, N/A
• Fits 1986-1998 Ford Taurus, N/A
• Fits 1995-1998 Ford Windstar, N/A
• Fits 1986-1998 Mercury Sable, N/A
• Fits 1986-1997 Ford Aerostar, N/A
• Fits 1992-1994 Ford Tempo, N/A
• Fits 1992-1994 Mercury Topaz, N/A
• Fits 1990-1992 Ford Probe, N/A
